KR102345638B1 - Non-face-to-face movement management platform system for the disabled - Google Patents

Abstract

A non-face-to-face exercise management platform providing system for the disabled according to the present invention, a client server including a video education platform for interactively outputting the audiovisual image to a display by generating an audiovisual image of the instructor and the disabled based on a microphone and a camera; a basic information input module for inputting basic information including the age, disability grade, height, and weight of the disabled; an exercise class generation module for classifying the basic information to generate an exercise class for the disabled; an exercise program generating module for generating an exercise program according to the exercise class; and an exercise service execution module configured to set the exercise image generated by the instructor based on the exercise program as an audiovisual image of the instructor and output it to the display.
According to the non-face-to-face exercise management platform providing system for the disabled according to the present invention, it provides an effect of providing a healthy environment in which the socially weak, the disabled, can comfortably and more conveniently perform exercise in a non-face-to-face manner.

Description

Non-face-to-face movement management platform system for the disabled

The present invention relates to a system for providing an exercise management platform for the disabled in a non-face-to-face manner, and in more detail, an instructor who educates the exercise and the disabled who receives the exercise can efficiently educate the exercise of the disabled even in a non-face-to-face state away from the disabled exercise It relates to a system for providing an exercise management platform specialized for the disabled that can actively promote the environment.

Thanks to the improvement of living standards and eating habits, unlike in the past, modern people tend to make exercise a habit to manage their own health, and various exercise education programs and exercise tools are being developed in response to this.

However, in the case of the disabled, not the general public, there is a problem in that it is difficult to exercise with the general public at a general training center, and in particular, in 2021, in a situation where social distancing is implemented due to the corona virus, it is not a situation where several people can gather and exercise together. have.

The disabled have the characteristics to perform exercise training professionally with a special purpose and exercise program along with rehabilitation exercise, and especially need the help of a professional instructor above all else.

To prevent this problem, there is a need for online exercise education for the disabled in a non-face-to-face manner, just like the current online education for elementary/middle/high schools. .

As an example, domestic patent No. 2233725, 5G-based multi-health care service smart home platform system and its driving method, includes an IoT home appliance that collects and transmits individual environmental data, a health device that collects and transmits individual life data, and a smart home device including a medical device that collects and transmits individual health data; a smart home control device for receiving and integrating data collected from the smart home device and interoperating; a cloud hub server for receiving and calculating the integrated data from the smart home control device; And it is disclosed that it can take care of exercise and health in a non-face-to-face manner for the socially underprivileged, etc., who cannot take care of themselves, including a health care unit that receives and monitors data calculated from the cloud hub server.

However, according to the above technology, not only the economic burden and cost of constructing several complex devices, but also the socially underprivileged have to exercise on their own, so it is impossible to provide a separate environment where they can conveniently receive practical exercise through an instructor. Problems follow.

Therefore, we provide a new and advanced exercise management platform for the disabled that can perform efficient exercise education tailored to the characteristics of the disabled in an environment where they can conveniently receive exercise under the guidance of the instructor through online exercise education in a non-face-to-face manner The need to develop a system is emerging.

The present invention has been devised to overcome the problems of the above technology, and it provides an environment in which a non-face-to-face video exercise can be customized according to the condition of the disabled for the disabled who is difficult to properly exercise outdoors. Its main purpose is to provide a management platform providing system.

Another object of the present invention is to include a means for providing and analyzing a separate questionnaire for the disabled in addition to video exercise and then providing customized health information to the disabled.

Another object of the present invention is to provide an exercise support terminal that can specifically grasp manipulations such as pulling and rotating as being operated by the disabled to more accurately and rationally check the exercise state of the disabled.

It is a further object of the present invention to provide a means for strengthening reflexes or improving concentration by reducing the delay time of the disabled during exercise through the above-described exercise support terminal.

In order to achieve the above object, the non-face-to-face exercise management platform providing system according to the present invention generates an audiovisual image of an instructor and a disabled person based on a microphone and a camera, and interactively outputs the audiovisual image to a display. client server including platform; a basic information input module for inputting basic information including the age, disability grade, height, and weight of the disabled; an exercise class generation module for classifying the basic information to generate an exercise class for the disabled; an exercise program generating module for generating an exercise program according to the exercise class; and an exercise service execution module that sets the exercise image generated by the instructor based on the exercise program as an audiovisual image of the instructor and outputs it to the display.

In addition, the system includes an authentication module comprising: an ID authentication unit generating and authenticating an ID of a disabled person through a mobile terminal supporting fingerprint recognition; and an authentication transmitting unit providing the ID and authentication status to the instructor characterized in that

In addition, the system includes a health information providing module having a questionnaire providing unit for providing a questionnaire to the disabled, and a health information providing unit for providing health information about the disabled to the disabled by analyzing the questionnaire written by the disabled; characterized by including.

According to the non-face-to-face type of disabled exercise management platform providing system according to the present invention,

1) It is possible to provide a healthy environment in which socially disadvantaged persons with disabilities can perform exercise safely and more conveniently in a non-face-to-face manner;

2) By conducting a separate questionnaire from the exercise video, customized health information can be provided for each disabled person,

3) While supporting various exercise methods through the exercise support terminal, the instructor can accurately grasp the exercise status of the disabled, as well as

4) It provides the effect of building an environment that can increase the efficiency of exercise by focusing more on the exercise support terminal.

1 is a system configuration diagram showing a server configuration of the system of the present invention;
2 is a block diagram showing the detailed configuration of the system of the present invention.
3 is a conceptual diagram illustrating an audiovisual image of an instructor and a disabled person output on a display.
4 is a conceptual diagram illustrating an embodiment of recognizing an ID of a disabled person by interworking with a mobile terminal.
5 is a conceptual diagram illustrating an exercise state of a disabled person through an exercise support terminal.
6 is a conceptual diagram illustrating an embodiment in which a badminton cock is mounted on a string structure of an exercise support terminal.

Hereinafter, preferred embodiments of the present invention will be described in detail with reference to the accompanying drawings. The accompanying drawings are not drawn to scale, and like reference numbers in each drawing refer to like elements.

1 is a system configuration diagram showing the server configuration of the system of the present invention.

As can be seen from FIG. 1 , the system of the present invention consists of a combination or interworking configuration of a client server owned by the instructor, that is, a client server 10 for the instructor, and a client server possessed by a person with a disability, that is, a client server 20 for the disabled. have.

In particular, according to the system of the present invention, a 1:N method of exercise education in which several disabled persons can receive exercise education based on one instructor is possible. Referring to FIG. 1 , one instructor client server 10 It is possible for a plurality of client servers for the disabled 20 to be communicatively interlocked.

In this way, the system of the present invention is based on a combination configuration of a plurality of client servers 10 and 20, and mainly transmits various information or data to be described later from the client server 20 for the disabled to the instructor client server ( 10), a main server (not shown) capable of communicating with each of the client server 10 for the instructor and the client server 20 for the disabled is provided separately, so that the client for the disabled from the main server It is also possible to analyze the information transmitted from the server 20 and transmit it to the instructor client server 10 .

That is, in the system of the present invention, the configuration and functions to be described later can be specified through the detailed functions of the instructor client server 10 or the main server, and the hardware and software of the instructor client server 10 or the main server are implemented. A description of the basic configuration is as follows. Of course, the client server 20 for the disabled may also be embodied including the following detailed configuration.

Instructor's client server 10 or main server is a hardware base having a central processing unit (CPU) and storage means such as memory and hard disk, a program that can be executed in the central processing unit, that is, software is installed and the software is installed. It can be implemented, but a series of specific configurations for such software will be described later as structural units called 'modules', 'parts', and 'interfaces'.

At this time, the lecturer's client server 10 or the main server temporarily and/or permanently stores a signal (or, data) processed therein. RAM (Random Access Memory, not shown) and ROM (ROM: Read -Only Memory, not shown), may include a processor.

The processor may include one or more cores (not shown) and a graphic processing unit (not shown) and/or a connection path (eg, a bus, etc.) for transmitting and receiving signals to and from other components.

The memory may store programs (one or more instructions) for executing and controlling a module or a unit to be described later. Programs stored in the memory may be divided into a plurality of modules according to functions.

The steps of a method or algorithm described in relation to an embodiment of the present invention may be implemented directly in hardware, as a software module executed by hardware, or by a combination thereof. A software module may include random access memory (RAM), read only memory (ROM), erasable programmable ROM (EPROM), electrically erasable programmable ROM (EEPROM), flash memory, hard disk, removable disk, CD-ROM, or It may reside in any type of computer-readable recording medium well known in the art to which the present invention pertains.

That is, the components of the present invention may be implemented as a program (or application) to be executed in combination with a computer, which is hardware, and stored in a medium. Components of the present invention may be implemented as software programming or software components, and similarly, embodiments may include various algorithms implemented as data structures, processes, routines, or combinations of other programming constructs, including C, C++ , may be implemented in a programming or scripting language such as Java, assembler, or the like. Functional aspects may be implemented in an algorithm running on one or more processors.

The configuration of these 'modules' or 'parts' or 'interfaces' is installed and stored in the storage means of the instructor's client server 200 or main server, software or hardware such as FPGA or ASIC that is executed via CPU and memory. means the work composition of In this case, the configuration of 'module', 'unit', and 'interface' is not limited to hardware, and may be configured to be in an addressable storage medium or may be configured to reproduce one or more processors. As an example, 'module' or 'part' or 'interface' refers to components such as software components, object-oriented software components, class components and task components, processes, functions, and properties. , procedures, subroutines, segments of program code, drivers, firmware, microcode, circuitry, data, databases, data structures, tables, arrays and variables.

A function provided by a 'module' or 'part' or 'interface' may be combined with a smaller number of components and 'units' or 'modules' or further with additional components and 'units' or 'modules' can be separated.

Hereinafter, the detailed configuration and function of the system of the present invention including the client for the disabled client 20 and the server while being implemented as the client server 10 or the main server for instructors based on such a macroscopic configuration will be described below.

2 is a block diagram showing the detailed configuration of the system of the present invention.

As can be seen from FIG. 2 , the system of the present invention includes client servers 10 and 20 for instructors/disabled persons including a video education platform 1 , a basic information input module 110 , and an exercise grade generation module 120 . ), an exercise program generating module 130 , and an exercise service execution module 140 are basically included.

First of all, the client server, that is, the client server 10 for instructors and the client server 20 for the disabled is based on the above-described hardware and software as described above, and programs or web/apps to the client servers 10 and 20 are The video education platform 1 installed in the form of an application provides a function of interactively outputting the audiovisual image to the display by generating an audiovisual image of the instructor and the disabled based on the microphone 2 and the camera 3 .

In other words, the client servers 10 and 20 basically include hardware such as a microphone 2, a camera 3, and a display 4, and these client servers 10 and 20 are generally known smart It may be exemplified by types such as a phone, a tablet PC, and a general personal computer (PC), but is not limited thereto.

The video education platform 1 of the present invention performs the same or similar function as a known non-face-to-face video education program, for example, a web such as 'ZOOM', a non-face-to-face video education platform for current elementary/middle/high school students. /App It can be understood as performing the same or similar function as an application (or platform or program).

That is, since the video education platform 1 of the present invention is the same as a known video education platform, a separate description may be omitted. 10, 20) installed on the server, respectively, by recording the instructor/disabled person through the microphone (2) and the camera (3) to create an audio-visual image, and then transmit this audio-visual image through the communication means installed in the client server (10, 20) It is transmitted interactively to the remote client server (for the instructor - for the disabled) and transmits the audiovisual image of the opposite party to the client server for instructors/disabled people (10, 20) respectively (audio-visual images taken by the disabled on the client server for the instructor and the client for the disabled The server performs the function of outputting audiovisual images taken by the instructor.

In this case, in particular, the audiovisual image for the instructor may be a pre-recorded audiovisual image or may be an audiovisual image taken in real time.

Such a video education platform 1 is equipped with a basis for performing exercises to be described later while checking each other's audiovisual images in a non-face-to-face manner even if the instructor and the disabled are remotely located.

The basic information input module 110 provides detailed information of the disabled person through the disabled client server 20, for example, age, gender, disability grade, disability sport/part (visually impaired, hearing impaired, etc.), height, weight, as well as exercise Provides a function to receive information such as experience (exercise history) and generate it as basic information.

The detailed items of such basic information are exemplary, and it is of course possible to include additional information such as health status and recent medical records in addition to the detailed information described above. Here, the disability grade can be understood as a concept including both the past grade and the current grade, as if the disability grade was previously classified according to the same criteria as grades 1 to 6, it is currently classified as severe/mild.

This basic information of the disabled provides the basis for the instructor to understand the basic state of the disabled to perform the motor skills.

The exercise grade generation module 120 receives the basic information of the disabled from the client server 10 for the disabled, and classifies the basic information by the disabled in the instructor client server 20 (or main server) to classify each disabled person's exercise grade play a role in determining

Here, it can be understood that the exercise grade does not mean a grade in which an exercise is performed, but is for determining an exercise program (exercise item and exercise intensity) that can be performed based on the basic information of the above-described basic information. In particular, age and disability grade can be the main factors in determining the exercise grade, and if the basic information includes the exercise history of the disabled, the exercise grade can be set as an incidental factor through this exercise history.

For example, if a person with a disability named A is explained as a criterion, an exercise program suitable for a 50-year-old male, a mild grade for the visually impaired, and 170cm/75kg is determined according to the 50-year-old level, but sports that use a lot of the eyes are excluded considering that the person is visually impaired. And if you have exercised in the last 1 month, you can determine the exercise intensity as a lower grade.

In addition, these exercise grades can be divided into, for example, 1 to 4 stages for each disability sport, stage 1 is basic exercise intensity, stage 2 is intermediate exercise intensity, stage 3 is advanced exercise intensity, and stage 4 is master exercise intensity. It is possible to classify as follows, and of course, it can also be classified according to various other classification criteria.

The exercise program generation module 130 is executed in the instructor client server 10, and provides a function for the disabled to generate an exercise program through the instructor according to the exercise grade.

In the present invention, the term 'exercise program' refers to exercise education information or exercise schedule information performed with the participation of one or more persons with disabilities under the subject of an instructor. It can be said that information including exercise time, such as 3 to 3 repetitions, and exercise intensity, such as repeating 3 sets of 15 repetitions of lifting 10 kg of dumbbells.

Such an exercise program can be implemented as a plurality of exercise program databases subdivided according to the basic information of the disabled. It is possible to include a function of selecting an exercise program suitable for the exercise class of the disabled person from the pre-made exercise program database.

3 is a conceptual diagram illustrating an audiovisual image of an instructor and a disabled person output on a display.

The exercise service execution module 140 of the present invention converts an audiovisual image of an instructor among the above-mentioned audiovisual images through the client server 10 for an instructor to an image generated by the instructor based on the above-described exercise program, that is, 'exercise image'. Specifically, by outputting to the display 4 of the client server 10 for the instructor as well as the client server 20 for the disabled, the disabled person can follow the exercise while watching the exercise video in a non-face-to-face manner.

In FIG. 3, the instructor's exercise image is output from the instructor's client server 10 and delivered to the client server 20 for the disabled, and then output to the display 4 included in or connected to the client server 20 for the disabled so that the disabled can report it Examples that can be followed are illustrated.

At this time, in the display 4 connected to the client server 10 for instructors or the display 4 connected to the client server 20 for the disabled, it is possible to display an exercise video as well as an image of a person with a disability watching and following the exercise video, including other images. It is possible to output all the images of the disabled person exercising on the divided screen.

These exercise videos are recorded videos made in advance by the instructor, and while the recorded video is output, the instructor can provide exercise guidance or coaching to a specific person with a disability while watching the audiovisual video of the disabled person following the exercise, or the instructor can exercise in real time As a video of the exercise, the instructor can also provide exercise guidance/guides for a specific disabled person while checking the audiovisual image of the disabled person during exercise.

At this time, the disabled can exercise alone while watching the above-mentioned instructor's exercise video, or exercise video according to the guidance of the guardian in a state accompanied by a guardian such as a parent (for example, the visually impaired who cannot see the exercise video) You can follow the movement of

In summary, according to the system of the present invention, as of 2021, in a situation where social distancing is being implemented due to the current corona virus, it is a characteristic that disabled people who are suffering from various disabilities can remotely perform an exercise suitable for their level in a non-face-to-face manner. to provide.

4 is a conceptual diagram illustrating an embodiment of recognizing an ID of a disabled person by interworking with a mobile terminal.

Referring to FIG. 4 , it can be seen that the system of the present invention may further include an authentication module 150 .

Specifically, the authentication module 150 provides a basis for the instructor to conveniently identify each of these as well as a basis for the disabled who cannot freely use their fingers to easily recognize themselves as several disabled people exist in one group. As such, it includes an ID authentication unit 1510 and an authentication transmission unit 152 .

The ID authentication unit 151 recognizes the fingerprint of the person with a disability in a state in which the terminal supporting fingerprint recognition by installing a separate application or program and the client server 20 for the disabled are interlocked, and stores it as authentication information, and then When the disabled access (login) to the video education platform 1, it provides a function of performing fingerprint authentication by requesting fingerprint recognition as login information.

At this time, the terminal supporting fingerprint recognition is made of a smartphone with a fingerprint recognition function, which is currently widely used, and supports fingerprint recognition in this smart phone. It is preferred that this be installed.

The authentication delivery unit 152 uses the authentication value for whether a specific disabled person has accessed the video education platform 1 (in this case, the access time check function can also be supported) in the ID and ID authentication unit for each disabled person. It performs a function of transmitting to the client server (10).

In this case, the ID for each disabled person may be transmitted to the client server 10 for instructors together with the basic information of the disabled person.

By this authentication module 150, the instructor can identify the specific disabled person before exercise training as well as easily determine whether the disabled person has participated in the exercise program progress time on the currently scheduled video education platform 1 to provide.

Additionally, it is possible for the system of the present invention to include a health information providing module 160 that can individually and specifically identify a health condition or a need for exercise in addition to the basic information of the disabled.

The health information providing module 160 may include a questionnaire providing unit 161 and a health information providing unit 162 .

The questionnaire providing unit 161 performs a function of transmitting a questionnaire prepared in advance by the instructor from the instructor client server 10 to the disabled client server 20 . In this case, the questionnaire may consist of information containing various contents such as recent health status, food intake (diet), personal needs, desired exercise type or intensity for each disabled person.

In addition, the questionnaire providing unit 161 has a function of not only providing a questionnaire to the disabled, but also receiving the questionnaire written by each disabled person again and analyzing the questionnaire.

The health information providing unit 162 analyzes the questionnaire written by the disabled and provides a function of delivering health information about the disabled to the disabled (specifically, a client server for the disabled).

Here, the health information includes diet information, such as information delivered by a known personal trainer to members, or exercise request information including exercise items and intensity that need to be carried out personally in addition to the exercise conducted on the video education platform 1, in usual times. It may include various information such as lifestyle information.

This health information providing module 160 does not unilaterally provide uniform exercise images to the disabled, but provides individually specialized or customized health information for each disabled person so that the disabled person can improve their health in daily life. provide a sound foundation for

5 is a conceptual diagram illustrating an exercise state of a disabled person through an exercise support terminal.

By the system of the present invention described above, the instructor can individually guide the disabled person while checking the audiovisual image in which the disabled person follows the exercise image, but, for example, only the audiovisual image of the disabled person when doing strength training The problem is that it's hard to figure out whether you're doing this exercise with the right amount of force.

In order to solve this problem, it is possible for the system of the present invention to further include an exercise support terminal 200 .

As can be seen from FIG. 5 , the exercise support terminal 200 provides information for more specifically understanding the exercise state of the disabled, and basically includes a string structure 210 .

The string structure 210 is an elastic material and refers to a kind of string or band extending in the direction of gravity in a string shape. The disabled person can hold the upper and lower ends of the string structure 210 with both hands in a state extended to a certain length like a known elastic exercise band without having to take an extended structure, or hanging from the ceiling, or the like, or further, the string structure It is possible to form an assembly with a frame surrounding the 210 .

The string structure 210 is preferably made of an elastic material to enable circular restoration during pulling operation, and it is also possible that a ring is formed at one end of the string structure 210 so that the handicapped person can easily fix their hands or feet. .

In this case, the string structure is capable of not only grasping the pulling operation of the disabled, but also grasping the pushing operation and swinging operation state by the direction sensor to be described later.

In particular, the above-described string structure 210 includes a plurality of tension sensor 211 and direction sensor 212 provided along the outer peripheral surface and the longitudinal direction.

The tension sensor 211 performs a function of measuring the pressure for the degree that the handicapped person pulled the string structure 210, that is, pulled or stretched, and whether the handicapped person pulled the string structure 210 and how much force It provides a measure to determine whether or not

In addition, the direction sensor 212 provides a measure capable of determining whether the handicapped person pulled or pushed (or shook) the string structure 210 in which direction.

That is, the string structure 210 of the present invention provides information on any one of the state information of the handicapped person pulling the string structure 210 through the tension sensor 211 and the direction sensor 212, meme, shaking, and rotation as well as Operation information including direction information at this time may be generated.

The tension sensor 211 and the direction sensor 212 can mount a known tension/direction sensor on the string structure 210 , and a detailed description of the structure thereof will be omitted.

It is possible to detect that a person with a disability pulls, pushes, or shakes the string structure 210 through the functions of the tension sensor 211 and the direction sensor 212. In response, the string structure 210 as well as the handicapped person For the client server 20 can transmit the operation information generated in the string structure 210 to the client server 20 for the disabled through a communication function through the communication function in a state including a short-range wireless communication (eg, Bluetooth) means. .

In addition, it is also possible that a separate controller is mounted on the client server for the disabled or interlocked through a communication means so that the controller can control special operations of the tension sensor 211 and the direction sensor 212 .

In addition, the exercise service execution module 140 includes an operation instruction unit 141 and an operation information providing unit 142 .

The operation instruction unit 141 allows the handicapped person to use the string structure 210 while the instructor's exercise image is output to the display 4 of the instructor/disabled client server 10, 20 or transmitted to the client server 20 for the handicapped. It performs the function of instructing the pulling operation for

For example, the operation instruction unit 141 may receive the sound directly exclaimed by the instructor 'pull the string' through the microphone 2 and include it in the exercise video as it is, but the specific content of the recorded exercise image may be pre-recorded. When the instructor performs a demonstration action of pulling the string structure 210 in the exercise video by analyzing it, automatically a visual notification (outputs the character 'pull' in text format) or sound message notification ('pull' in sound format) output sound), etc., may instruct a person with a disability to perform a pulling operation on the string structure 210 .

The operation information providing unit 142 transmits the operation information for each disabled person generated by the tension detection sensor 211 and the direction detection sensor 212 of the string structure 210 to the instructor client server 20, so that the instructor is more Specifically, it provides a function to understand the exercise status of individual disabled people.

In other words, in the audiovisual image of the disabled who can only vaguely check with the naked eye, it is difficult to properly determine whether the disabled person pulled the string structure 210 by how much force, but specific tension numerical information according to the operation information providing unit 142 As the instructor can understand the details, it is possible to establish a basis for understanding whether the person with the disability is using tricks or the athletic ability of the person with disabilities.

According to such a configuration, it provides the characteristic that a remote instructor can specifically grasp the exercise ability of the disabled, which can be said to be the limit of the non-face-to-face method.

6 is a conceptual diagram illustrating an embodiment in which a badminton cock is mounted on a string structure of an exercise support terminal.

Exercises that can be performed by applying the above-described string structure 210 include various exercises such as a muscle strength exercise that pulls or spreads the hand or foot of the disabled person, a balance exercise that performs rotation with the hand or foot, and an endurance exercise that maintains a pulled state. However, it is not limited thereto, and if a badminton shuttlecock is hung on a ring (not shown) formed at the end of the string structure 210 or a sandbag is mounted, an exercise to hit the shuttlecock with a badminton racket or a movement to hit a sandbag can be performed. have.

6 shows an embodiment in which badminton exercise can be performed through the string structure 210, and the string structure 210 is hung from the ceiling as in the above-mentioned example, and then the ball 220 (at the lower end) ( Specifically, it is possible to provide a basis for performing badminton exercise by hanging a badminton shuttlecock.

Specifically, a person with a disability can swing a shuttlecock suspended from the string structure 210 while holding a badminton racket, and through this, the tension sensor 211 and the direction sensor 212 (in this case, direction information is particularly important rather than tension) information) can generate operation information and deliver it to the instructor client server 10 .

In this case, the operation instruction unit 141 may include a function of instructing the disabled to hit the ball 220 suspended from the string structure 210 using a tool such as a racket or directly by hand while the motion image is output. .

In the embodiment of Figure 6, the badminton exercise is exemplified, but it is limited to me, and as mentioned above, a punching bag or various exercise balls are hung at the lower end of the string structure 210 to perform more colorful and interesting exercises with the disabled. environment can be built.

Additionally, through the above-described exercise support terminal 200, it is possible to grasp the instantaneous power of the disabled by understanding the difference between the instructor's operation instruction point and the actual string structure 210 when the handicapped person manipulated it. The service execution module 140 may include a delay determining unit 143 .

The delay determining unit 143 includes an image analysis program, or by analyzing the tension value of the tension sensor 211 as described above, the time when the instructor instructed the pulling operation in the exercise image and the disabled person in the audiovisual image of the disabled person It performs a function of generating delay information by analyzing a time difference between the actual times when the string structure 210 is pulled.

For example, when a specific disabled person pulls the string structure 210 3 seconds after the instructor instructs the pulling operation, it provides a basis for understanding that the disabled person has low or no reflex. At this time, if the delay information is at the level of 1 or 2 seconds, it can be regarded as a normal state within the range of general reflexes, but if it is 3 seconds or more, it can be objectively determined that the disabled person lacks or lacks agility.

There may be various methods to improve this instantaneous power, but in particular, the operation instruction unit 141 of the present invention includes a function of adjusting the number of pulling operations on the string structure 210 according to the high and low values of the delay information. can be

That is, in the above example, if the disabled person shows delay information (delay time) of 3 seconds and lacks instantaneous power, originally, it is basic to pull the string structure 210 once, but the operation instruction unit 141 instructs to pull it twice. This means that if the basic rule is 3 pulls for a disabled person with good agility, it can be adjusted in a way that reduces the number of pulls to 2 times.

By such a configuration and function, it is possible to provide a characteristic capable of enhancing the instantaneous power of the disabled by grasping the instantaneous power of the disabled and then operating the string structure 210 in a differential/variable number of times according to the degree of instantaneous power.

Unlike the general public, people with disabilities such as ADHD are not able to concentrate even when instructed to pull the string structure 210 and are distracted, such as playing pranks or hanging on the string structure 210, or consciously concentrating on the person with disabilities themselves. There is a possibility that an unfortunate phenomenon of not being able to pull the string structure 210 may occur.

To this end, in the present invention, it is possible to provide a separate detailed configuration that can enhance the concentration on the pulling operation of the string structure 210 of the disabled.

Specifically, the exercise service execution module 140 of the present invention detects that the disabled person cannot concentrate on the string structure 210 of the exercise support terminal 200 or is playing unnecessary pranks, and in this case, a distraction detection that provides a notification The concentration of the disabled can be strengthened by further including the part 144 .

Specifically, the distraction detecting unit 144 basically includes a tension sensing part 144a, a direction sensing part 144b, a concentration part 144c, and a notification providing part 144d.

The tension sensing part 144a performs a function of determining the number of pressurizations, which is the number of times the handicapped person pulls the string structure 210 based on the tension applied to the pressure sensor 211 mounted on the string structure 210, the string It is assumed that when pressure (tension) is simultaneously sensed by a plurality of tension sensors 211 mounted at regular intervals along the extension direction of the structure 210, the pulling operation of the string structure 210 by the disabled has occurred once. and performs a function of determining the number of times the person with disabilities performs a pulling operation on the string structure 210 while watching the exercise image, that is, the number of times the string structure 210 is pulled.

This is to determine the total number of pressurization by counting the number of pressurizations one by one as the pressure is sensed simultaneously by the plurality of tension sensors 211 while the disabled person performs an exercise based on the exercise image.

The direction sensing part 144b is the maximum swing angle of the string structure 210 through the movement (rotation) direction of the string structure 210 sensed through the direction detection sensor 212 also mounted on the string structure 210 . It performs the function of calculating

This goes beyond detecting that the string structure 210 is shaken through the direction sensor 212, and determines how much it shakes, that is, the maximum shake angle, and this maximum shake angle is based on the direction of gravity. (0 degree) is to calculate how large the degree of shaking (the string structure 210 is tilted). In other words, in a state in which the direction of gravity toward which the string structure 210 is directed is defined as 0 degrees, even if the string structure 210 is tilted to the left by 40 degrees or tilted to the right by 40 degrees, the maximum swing angle is the same as 40 degrees.

The attention part 144c serves to determine whether the disabled person's attention is focused on the basis of the number of times of pressing and the maximum shaking angle. It is more preferable to determine whether attention is focused through Equations 1 to 2.

Equation 1,

Equation 2,

는 주의집중 산출값,

는 흔들림가중치,

는 최대흔들림각도,

는 기준흔들림각도,

는 당김가중치,

는 장애인이 스트링 구조체를 당긴 횟수,

는 장애인의 주의집중여부 판단값,

는 산만도 기준값을 의미한다.here,

is the attention output value,

is the vibration weight,

is the maximum oscillation angle,

is the standard oscillation angle,

is the pull weight,

is the number of times the disabled person pulled the string structure,

is the judgment value of whether the disabled person's attention is focused,

is the standard value of distraction.

라 함은 운동 지원 단말(210)이 배치되는 환경에 따라 바람 등에 의해 자연적으로 흔들릴 수 있는 각도로서, 이는 환경에 따라 달라지므로 설정값에 제한을 두지 않아 강사나 시스템 관리자가 기준흔들림각도를 설정할 수 있으나, 바람직하게는 0°내지 45°범위일 수 있다.At this time, in Equations 1 and 2, the standard shaking angle

This is an angle that can be naturally shaken by wind, etc. depending on the environment in which the exercise support terminal 210 is disposed, and since it varies depending on the environment, there is no limit to the set value, so that the instructor or the system administrator can set the standard shaking angle However, it may preferably be in the range of 0° to 45°.

Also, depending on the environment in which the exercise support terminal 210 is disposed, the shaking weight may be set low in an environment in which shaking is severe to prevent a high concentration of attention calculated value due to simple shaking, etc., preferably It can be adjusted in the range between 0 and 10 (relative value). This can also be pre-adjusted by the system administrator.

The pull weight is set in consideration of the subject of the present invention being a disabled person, and when the disabled person is mentally ill or physically disabled, the probability of manipulating or pulling the exercise support terminal 30 by mistake or playfully increases, , it can be said that the severity is particularly severe when the disabled person is as young as a child.

However, in this case, rather than directly determining that the person with disabilities is a distraction, it may be a characteristic of the person with a disability or a characteristic of the sport.

Therefore, it can be called a weight for correcting this, and it can be preferably adjusted in the range of 0 to 10, but the younger the disabled person is, the lower the pull weight, and the higher the age of the disabled, the higher the pull weight can be calculated. .

Therefore, primarily through Equation 1, the handicapped person shakes the string structure 210 at an angle greater than the standard shaking angle, and how many times the pulling operation is performed on the string structure 210 in addition to the instructor's pulling operation instruction point in the exercise image. After comparing them, weights are given to them to calculate the concentration of attention.

Next, through Equation 2, the calculated concentration of attention is compared with the standard value of distraction, and when the calculated value of concentration is greater than or equal to the standard value of distraction, it is determined that the disabled person is not able to concentrate and is distracted. If the concentration calculation value is less than the distraction standard value, it is judged that the disabled person is paying attention, and the pass result is displayed.

At this time, the standard value of distraction is again adjusted by a system administrator, instructor, or a separate specialist for the disabled and can be adjusted according to the clinical result. There is no limit to the range of the standard of distraction, so the age, gender, personality, disability, and degree of the disabled person is not limited. , the standard of distraction may be adjusted according to the learning attitude in the past.

For example,

인 경우,

If ,

이고,

ego,

는

보다 큰 값이므로,calculated in this way

Is

Since it is a larger value,

값이 출력되어 해당 장애인은 주의집중을 하지 못하는 것으로 판단될 수 있다.

As the value is output, it can be determined that the disabled person is unable to concentrate.

Therefore, by the above-described algorithm, it is rationally and efficiently judged whether or not attention is concentrated in the attention-focused part.

Finally, the notification providing part 144d performs a function of providing a notification message to the disabled (client server for the disabled) according to whether the disabled person concentrates, that is, a separate speaker to the disabled client server 20 If the display is built-in, the above-described notification message may be provided through the corresponding client server 20 for the disabled.

Specifically, the notification message may be visually output on the display 4 mounted on or linked to the client server 20 for the disabled (output in the form of a pop-up window is possible) or a voice message (notification sound) based on the speaker. It is also possible that this output or a notification sound may be output).

At this time, the notification may simply have the meaning of a warning not to play a prank, but it is not a joke, but a soft and gentle nuance as much as possible according to the unique characteristics of the disabled that attention can be perceived as a distraction even if the string structure 210 is consciously pulled. It is also possible to include messages of encouragement.

Through such a configuration, the system of the present invention performs the characteristic of providing the above-described notification when a person with a disability plays a prank with the string structure 210 or shows a distraction attitude such as pulling without concentrating differently than intended. .

Additionally, the string structure 210 may include an elastic reinforcing layer in order to prevent a problem that deformation is generated or durability is weakened by manipulation such as frequent pulling.

Specifically, the string structure 210 may be made of an elastic material such as rubber or silicone as described above. In addition, the surface of the string structure 210 is made of thermoplastic polyurethane (TPU) and melamine resin and azo An elastic reinforcing layer prepared by mixing dicarbonamide (Azodicarbonamide) may be laminated.

Thermoplastic polyurethane (TPU) is widely used as a structural material that replaces rubber, such as cell phone cases, cushioning mattresses, and fire hoses, because it is not only tough and has excellent elasticity as well known, but also has a shock-absorbing function.

That is, by enhancing the elasticity of the string structure 210 to promote elastic repulsion, it is possible to enhance the durability of the string structure 210 and prevent unnecessary deformation from occurring at the same time.

In addition, the elastic reinforcing layer includes the aforementioned thermoplastic polyurethane (TPU) as well as melamine resin and azodicarbonamide.

For example, the elastic reinforcing layer may be composed of 75 to 90 parts by weight of thermoplastic polyurethane, 5 to 15 parts by weight of melamine resin, and 5 to 10 parts by weight of azodicarbonamide.

This elastic reinforcing layer is manufactured by melting thermoplastic polyurethane at 180 to 230°C, mixing melamine resin and azodicarbonamide, and then cooling it in a molding die, or together with polyol and isocyanate when thermoplastic polyurethane is manufactured. After mixing melamine resin and azodicarbonamide, it can be manufactured through incision and injection molding.

Melamine resin is a resin obtained by reacting melamine and formaldehyde, and has the characteristic of forming fine pores when foamed. It is compressed more easily than urethane, so that the impact applied to the elastic auxiliary layer is absorbed by the melamine resin, thereby providing a function of assisting the shock absorption of the thermoplastic polyurethane.

Azodicarbonamide is a material in which two CONH ₂ groups are connected by an azo group, which is a double bond between nitrogen and nitrogen, and serves to promote the formation of micropores in the melamine resin by releasing nitrogen from the amide group.

That is, while increasing the surface area of the string structure 210 by promoting the formation of voids on the surface of the string structure 210, the shock of the sludge is dispersed through the voids together with the elastic function of the above-described thermoplastic polyurethane (TPU). As a result, the role of reinforcing the elastic or elastic repulsive force of the string structure 210 may be strengthened while absorbing treatment.

Furthermore, the elastic reinforcing layer may provide an additional composition and a manufacturing method including the same in addition to the thermoplastic polyurethane, melamine resin, and azodicarbonamide in order to enhance the function of assisting the elasticity of the aforementioned thermoplastic polyurethane.

Specifically, the elastic reinforcing layer including the additional composition may be manufactured through a primary material preparation step, a secondary material preparation stage, a tertiary material preparation stage, a filtrate obtaining stage, and a completion stage.

First, the primary material preparation step is a process of preparing a primary material by mixing 85 to 95 parts by weight of isopropyl alcohol and 5 to 15 parts by weight of a melamine resin at 150 to 200° C. for 1 to 3 hours.

In this case, isopropyl alcohol is a solvent having excellent solubility in the carbon-oxygen portion of the melamine resin. That is, an excess of isopropyl alcohol is evaporated in the process of mixing at 150 to 200° C. for 1 to 3 hours by the primary material preparation step, thereby preparing a gel-like primary material containing a melamine resin as a main component.

Next, the secondary material preparation step is a process of preparing a secondary material by mixing 90 to 95 parts by weight of the primary material and 5 to 10 parts by weight of azodicarbonamide at 150 to 200° C. for 30 to 60 minutes.

Here, when azodicarbonamide is mixed with more than 10 parts by weight, the pore size of the melamine resin becomes excessively large, so it may be difficult for the melamine resin to support the impact. Since shock absorption through compression may not occur well, it is preferable to mix in the above-mentioned parts by weight.

In addition, at 200° C. or higher, the azo group of azodicarbonamide may be decomposed and color development may not occur, and below 150° C., the primary material does not flow well and mixing is difficult, so mixing at 150 to 200° C. is appropriate.

Subsequently, the tertiary material preparation step is performed by mixing 80 to 95 parts by weight of the secondary material, 5 to 20 parts by weight of dibutylmethyl phenol at 100 to 150° C. at 500 to 2000 rpm for 1 to 2 hours, and the tertiary material is the process of manufacturing

Here, dibutylmethylphenol is an antioxidant having a property of accepting radicals, and it can eliminate the possibility that radicals cause a curing reaction to lower elasticity, that is, it can prevent the elasticity of the elastic reinforcement layer from being lowered. can

The step of obtaining the filtrate is a process of mixing 20 to 30 parts by weight of the tertiary material and 70 to 80 parts by weight of acetone at 2000 to 3000 rpm for 10 to 30 minutes to obtain a filtered filtrate. Here, acetone is a solvent for dispersing the tertiary material.

Since this filtrate obtaining step is mixed at 2000 to 3000 rpm, an elastic auxiliary layer having various particle sizes can be obtained. It is possible to remove the poor component, which is difficult to achieve the function of absorbing it.

The completion step refers to a process of mixing 10 to 25 parts by weight of the above-mentioned filtrate and 75 to 90 parts by weight of thermoplastic polyurethane (TPU). During the thermoplastic polyurethane manufacturing process, it is possible to mix the above-mentioned filtrate with a polyol and an isocyanate, and then to manufacture it through injection molding or the like.

The elastic auxiliary layer manufactured through this process provides a basis for further increasing the elasticity of the above-described thermoplastic polyurethane and the shock absorbing function of the elastic auxiliary layer based thereon.

As described so far, the configuration and operation of the non-face-to-face type of disabled exercise management platform providing system according to the present invention are expressed in the above description and drawings, but this is only an example and the spirit of the present invention is reflected in the above description and drawings It is not limited, and various changes and modifications are possible without departing from the technical spirit of the present invention.

1: Video training platform 2: Microphone
3: Camera 4: Display
10: Client Server for Instructors 20: Client Server for the Disabled
110: basic information input module 120: exercise class generation module
130: exercise program generation module 140: exercise service execution module
141: operation instruction unit 142: operation information providing unit
143: delay detection unit 144: distraction detection unit
144a: tension sensing part 144b: direction sensing part
144c: attention part 144d: notification part
150: authentication module 151: ID authentication unit
152: authentication transfer unit 160: health information providing module
161: questionnaire provision unit 162: health information provision unit
200: exercise support terminal 210: string structure
211: tension sensor 212: direction sensor
220: ball

Claims (8)

As a non-face-to-face exercise management platform for the disabled,
A client server including a video education platform that generates an audiovisual image of an instructor and a disabled person based on a microphone and a camera and interactively outputs the audiovisual image to a display;
a basic information input module for inputting basic information including the age, disability grade, height, and weight of the disabled;
an exercise class generation module for classifying the basic information to generate an exercise class for the disabled;
an exercise program generating module for generating an exercise program according to the exercise class;
an exercise service execution module for setting an exercise image generated by an instructor based on the exercise program as an audiovisual image of the instructor and outputting it to the display;
In a state extending in the gravity direction in a string shape as an elastic material, an exercise support terminal including a string structure for generating manipulation information including a plurality of tension sensors and direction sensors provided along the outer circumferential surface and the longitudinal direction; includes; do,
The exercise service execution module,
an operation instruction unit for instructing a pulling operation on the string structure while the motion image is output;
an operation information providing unit for providing the operation information to the instructor; and
A tension sensing part for determining the number of times of pressing, which is the number of times the disabled person pulled the string structure, based on the tension applied to each of the tension sensor, and the string through the direction of movement of the string structure sensed through the direction sensor A direction sensing part for calculating the maximum shaking angle of the structure, an attention-focusing part for determining whether the disabled person's attention is focused on the basis of the number of pressurizations and the maximum shaking angle, and to the disabled person according to whether the disabled person's attention Includes a distraction detection unit including a notification providing part for providing a notification message,
The attention-grabbing part is
A system for providing an exercise management platform for the disabled, characterized in that it is determined whether or not attention is focused through the following Equations 1 to 2.
Equation 1,

Equation 2,

(here,

is the attention output value,

is the vibration weight,

is the maximum oscillation angle,

is the standard oscillation angle,

is the pull weight,

is the number of times the disabled person pulled the string structure,

is the judgment value of whether the disabled person's attention is focused,

is the standard value for the degree of distraction.) The method of claim 1,
The system is
A health information providing module having a questionnaire providing unit providing a questionnaire to the disabled, and a health information providing unit providing health information about the disabled to the disabled by analyzing the questionnaire written by the disabled , the disabled exercise management platform providing system. The method of claim 1,
The exercise support terminal,
and a ball suspended from the end of the string structure;
The operation instruction unit,
While the exercise image is output, the disabled exercise management platform providing system, characterized in that it comprises a function of instructing the disabled to hit the ball suspended on the string structure. 4. The method of claim 3,
The exercise service execution module,
and a delay grasper configured to generate delay information by analyzing the difference between the time when the pulling operation is instructed and the time when the person with a disability actually pulls the string structure,
The operation instruction unit,
The system for providing an exercise management platform for the disabled, characterized in that it includes a function of adjusting the number of pulling manipulations for the string structure according to the height of the numerical value of the delay information. The method of claim 1,
The string structure includes an elastic reinforcing layer,
The elastic reinforcing layer,
Preparing a primary material by mixing 85 to 95 parts by weight of isopropyl alcohol and 5 to 15 parts by weight of a melamine resin at 150 to 200° C. for 1 to 3 hours;
preparing a secondary material by mixing 90 to 95 parts by weight of the primary material and 5 to 10 parts by weight of azodicarbonamide at 150 to 200° C. for 30 to 60 minutes;
Preparing a tertiary material by mixing 80 to 95 parts by weight of the secondary material, 5 to 20 parts by weight of dibutylmethyl phenol at 100 to 150° C. at 1000 to 2000 rpm for 1 to 2 hours;
20 to 30 parts by weight of the tertiary material and 70 to 80 parts by weight of acetone are mixed at 2000 to 3000 rpm for 10 to 30 minutes and then filtered to obtain a filtrate;
10 to 25 parts by weight and a mixing step of mixing 75 to 90 parts by weight of thermoplastic polyurethane (TPU); Characterized in that produced through, the disabled exercise management platform providing system. delete delete delete

Images
