CN112562161A - Based on 5G thing networking and AI intelligent entrance guard integrated management system - Google Patents
Based on 5G thing networking and AI intelligent entrance guard integrated management system Download PDFInfo
- Publication number
- CN112562161A CN112562161A CN202011421723.0A CN202011421723A CN112562161A CN 112562161 A CN112562161 A CN 112562161A CN 202011421723 A CN202011421723 A CN 202011421723A CN 112562161 A CN112562161 A CN 112562161A
- Authority
- CN
- China
- Prior art keywords
- management unit
- personnel
- visitor
- access control
- block
- Prior art date
- Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
- Pending
Links
Images
Classifications
-
- G—PHYSICS
- G07—CHECKING-DEVICES
- G07C—TIME OR ATTENDANCE REGISTERS; REGISTERING OR INDICATING THE WORKING OF MACHINES; GENERATING RANDOM NUMBERS; VOTING OR LOTTERY APPARATUS; ARRANGEMENTS, SYSTEMS OR APPARATUS FOR CHECKING NOT PROVIDED FOR ELSEWHERE
- G07C9/00—Individual registration on entry or exit
- G07C9/30—Individual registration on entry or exit not involving the use of a pass
- G07C9/32—Individual registration on entry or exit not involving the use of a pass in combination with an identity check
- G07C9/37—Individual registration on entry or exit not involving the use of a pass in combination with an identity check using biometric data, e.g. fingerprints, iris scans or voice recognition
-
- G—PHYSICS
- G06—COMPUTING OR CALCULATING; COUNTING
- G06V—IMAGE OR VIDEO RECOGNITION OR UNDERSTANDING
- G06V40/00—Recognition of biometric, human-related or animal-related patterns in image or video data
- G06V40/10—Human or animal bodies, e.g. vehicle occupants or pedestrians; Body parts, e.g. hands
- G06V40/16—Human faces, e.g. facial parts, sketches or expressions
- G06V40/168—Feature extraction; Face representation
-
- G—PHYSICS
- G06—COMPUTING OR CALCULATING; COUNTING
- G06V—IMAGE OR VIDEO RECOGNITION OR UNDERSTANDING
- G06V40/00—Recognition of biometric, human-related or animal-related patterns in image or video data
- G06V40/10—Human or animal bodies, e.g. vehicle occupants or pedestrians; Body parts, e.g. hands
- G06V40/16—Human faces, e.g. facial parts, sketches or expressions
- G06V40/172—Classification, e.g. identification
-
- G—PHYSICS
- G07—CHECKING-DEVICES
- G07C—TIME OR ATTENDANCE REGISTERS; REGISTERING OR INDICATING THE WORKING OF MACHINES; GENERATING RANDOM NUMBERS; VOTING OR LOTTERY APPARATUS; ARRANGEMENTS, SYSTEMS OR APPARATUS FOR CHECKING NOT PROVIDED FOR ELSEWHERE
- G07C9/00—Individual registration on entry or exit
- G07C9/30—Individual registration on entry or exit not involving the use of a pass
- G07C9/32—Individual registration on entry or exit not involving the use of a pass in combination with an identity check
- G07C9/33—Individual registration on entry or exit not involving the use of a pass in combination with an identity check by means of a password
-
- G—PHYSICS
- G07—CHECKING-DEVICES
- G07C—TIME OR ATTENDANCE REGISTERS; REGISTERING OR INDICATING THE WORKING OF MACHINES; GENERATING RANDOM NUMBERS; VOTING OR LOTTERY APPARATUS; ARRANGEMENTS, SYSTEMS OR APPARATUS FOR CHECKING NOT PROVIDED FOR ELSEWHERE
- G07C9/00—Individual registration on entry or exit
- G07C9/30—Individual registration on entry or exit not involving the use of a pass
- G07C9/38—Individual registration on entry or exit not involving the use of a pass with central registration
-
- G—PHYSICS
- G16—INFORMATION AND COMMUNICATION TECHNOLOGY [ICT] SPECIALLY ADAPTED FOR SPECIFIC APPLICATION FIELDS
- G16Y—INFORMATION AND COMMUNICATION TECHNOLOGY SPECIALLY ADAPTED FOR THE INTERNET OF THINGS [IoT]
- G16Y40/00—IoT characterised by the purpose of the information processing
- G16Y40/30—Control
-
- H—ELECTRICITY
- H04—ELECTRIC COMMUNICATION TECHNIQUE
- H04L—TRANSMISSION OF DIGITAL INFORMATION, e.g. TELEGRAPHIC COMMUNICATION
- H04L67/00—Network arrangements or protocols for supporting network services or applications
- H04L67/01—Protocols
- H04L67/12—Protocols specially adapted for proprietary or special-purpose networking environments, e.g. medical networks, sensor networks, networks in vehicles or remote metering networks
Landscapes
- Engineering & Computer Science (AREA)
- General Physics & Mathematics (AREA)
- Physics & Mathematics (AREA)
- Health & Medical Sciences (AREA)
- Human Computer Interaction (AREA)
- General Health & Medical Sciences (AREA)
- Oral & Maxillofacial Surgery (AREA)
- Computing Systems (AREA)
- Multimedia (AREA)
- Theoretical Computer Science (AREA)
- Medical Informatics (AREA)
- Computer Networks & Wireless Communication (AREA)
- Signal Processing (AREA)
- Computer Vision & Pattern Recognition (AREA)
- Management, Administration, Business Operations System, And Electronic Commerce (AREA)
Abstract
The invention discloses a comprehensive management system for an intelligent access control based on a 5G Internet of things and AI, which comprises an intelligent access control terminal and a function module connected with the intelligent access control terminal through a 5G Internet of things technology; the functional module comprises an access control management unit which is used for limiting personnel to enter and exit; an authorization management unit: the system comprises a door control management unit, a door control management unit and a door control unit, wherein the door control management unit is used for sending an authorization instruction sent by an owner to the door control management unit; building management unit: the system is used for acquiring personnel arrangement information and personnel identity information inside the building; a personnel management unit: the system is used for acquiring the in-out time, the staying time and the business handling information of the personnel in the building; the invention provides a bidirectional visitor visit management mode, namely two modes of visitor active reservation application and owner active invitation are realized, visitor visit record, visitor authorization and issuing to an entrance guard, visitor time management, visitor path real-time map navigation and indoor AR navigation are synchronously combined, so that visitor management is safer and more controllable, and visitors can use more conveniently.
Description
Technical Field
The invention relates to the technical field of entrance guard management, in particular to an intelligent entrance guard comprehensive management system based on a 5G Internet of things and an AI.
Background
Most of the existing access control management systems are controlled by independent access control or are networked by using a wired network, a door opening controller for personnel to enter and exit is provided, the access control controllers are low in network connection speed, low in efficiency, poor in stability and single in function, and access authorization data need to be recorded or issued one by one. The existing networked access control system does not support access control modes in forms of autonomous reservation of visitors, active invitation of owners and the like.
When people visit, the existing access control system needs the personnel to search addresses and maps by themselves, so that the visiting positions and the indoor accurate positions of buildings, floors and rooms in the visiting place cannot be searched accurately.
The existing access control system does not comprehensively manage information such as buildings, houses, owners and the like, and personnel marking and personnel control management cannot be realized.
Disclosure of Invention
Additional features and advantages of the invention will be set forth in the description which follows, and in part will be obvious from the description, or may be learned by the practice of the invention. The objectives and other advantages of the invention will be realized and attained by the structure particularly pointed out in the written description and claims hereof as well as the appended drawings.
The invention aims to provide an intelligent access control comprehensive management system based on a 5G Internet of things and an AI (intelligent access control), so as to solve the problems in the background technology.
In order to achieve the purpose, the invention provides the following technical scheme:
a comprehensive management system based on a 5G Internet of things and AI intelligent access control comprises an intelligent access control terminal and a function module connected with the intelligent access control terminal through a 5G Internet of things technology;
the functional module comprises an access control management unit which is used for limiting personnel to enter and exit;
an authorization management unit: the system comprises a door control management unit, a door control management unit and a door control unit, wherein the door control management unit is used for sending an authorization instruction sent by an owner to the door control management unit;
building management unit: the system is used for acquiring personnel arrangement information and personnel identity information inside the building;
a personnel management unit: the system is used for acquiring the in-out time, the staying time and the business handling information of the personnel in the building;
visitor management unit: the system comprises a visitor, a client and a system server, wherein the visitor is used for receiving instruction information input by the visitor, auditing the information and sending the information to the owner;
a positioning navigation unit: the system comprises a target path providing unit, a target path providing unit and a target path providing unit, wherein the target path is used for providing a user to obtain an authorization management unit;
as a further scheme of the invention: the positioning navigation unit is used for receiving the access address sent by the visitor management unit, calling a building map and presenting a path indication map to the visitor handheld terminal by combining the AR technical block.
As a further scheme of the invention: the entrance guard management unit comprises a face recognition block, a voice recognition block, a fingerprint recognition block and a label recognition block, wherein the face recognition block, the voice recognition block, the fingerprint recognition block and the label recognition block are used for recognizing visitors.
As a further scheme of the invention: the personnel management unit comprises a marking block for intelligently marking different personnel identities and an alarm block for counting the access time of different personnel and giving an alarm according to the access time of the personnel with different identities, the alarm block is used for prompting the old in a management personnel cell to be inactive for a long time, accidents can occur, and theft and other things can occur when the access time of external personnel is too long.
As a further scheme of the invention: the authorization management unit comprises an invitation block which is convenient for a business owner to send an invitation command to the intelligent access control terminal, and the invitation block comprises visitor photo information, frequent place information and visiting time information.
As a further scheme of the invention: the building management unit comprises a camera block used for acquiring video information inside the building.
As a still further scheme of the invention: the recognition algorithm of the face recognition block, such as the analysis and recognition of data such as clothes color, clothes mark, hat color and the like, guides the intelligent learning and analysis of the intelligent access control system, establishes different identity character model libraries, and the algorithm analysis is carried out according to five steps of target acquisition, image processing, feature extraction and table feature classification, wherein the target acquisition acquires geometric features of a connected region through image scanning, including a minimum circumscribed rectangle, an area, a centroid and the like, a target region area parameter M (m) can be used as a measurement scale, and the region A (x, y), M (m) is defined as the number of pixels in the region, namely:
then according to the position of the target area, the centroid is taken as the measurement size, the target centroid is set as (Cx, Cy),
Cx＝M10(Ai(x,y))/M00(Ai(x,y))
Cy＝M01(Ai(x,y))/M00(Ai(x,y))
wherein the matrix is defined as:
the positions of the extreme points of the boundary outline of the target circumscribed rectangle, including the upper (t), the lower (b), the left (l) and the right (r), are calculated as follows:
the feature extraction follows image normalization; converting and quantizing the color space to obtain a color vector; for each block, the color or contour value is extracted, the formula is as follows:
the table feature classification calculation uses SVM to solve the multi-class classification problem, and uses fi(x) The i-1, 2, a, N function tests an arbitrary sample x of the image N for its class Gx as calculated by the following function:
and finally, judging whether a certain sample x belongs to the class c, firstly calculating z as phi (x), and then calculating the following decision function:
if f (z) is 1, x belongs to class c, otherwise it does not.
As a still further scheme of the invention: the AR technology block path navigation uses A-algorithm-based calculation optimization, and a calculation function formula is as follows:
cost(n)＝g(n)
f(n)＝g(n)+h(n)
where g (n) represents the back cost of the current node, h (n) represents the forward cost of the current node, but more people refer to h (n) as a heuristic function, and f (n) on the right is referred to as an evaluation function, the distance path calculation is calculated by using a manhattan distance calculation method, as follows:
D(N1,N2)＝|N1x-N2x|+|N1y-N2y|
because the manhattan distance satisfies the consistency and the characteristic of "h (gold) ═ 0", the calculation cost is low, and the calculation is simple and efficient.
Compared with the prior art, the invention has the beneficial effects that:
based on the 5G Internet of things technology, the invention enables the access control management system to provide application of high-definition face image recognition, video voice and other AI intelligent recognition technologies by utilizing the characteristics of high speed, low delay and large link of the 5G technology.
The invention realizes intelligent authorization of entrance guard by combining the comprehensive management of physical information of personnel, buildings, houses and the like.
The invention provides a bidirectional visitor visit management mode, namely two modes of visitor active reservation application and owner active invitation are realized, visitor visit record, visitor authorization and issuing to an entrance guard, visitor time management, visitor path real-time map navigation and indoor AR navigation are synchronously combined, so that visitor management is safer and more controllable, and visitors can use more conveniently.
The invention realizes personnel marking and personnel control management, and can carry out control management on different types or specific personnel through the system by intelligently marking the face identities of different personnel, so that the safety management is more intelligent and efficient.
It is to be understood that both the foregoing general description and the following detailed description are exemplary and explanatory only and are not restrictive of the disclosure.
Clearly, such objects and other objects of the present invention will become more apparent from the detailed description of the preferred embodiments hereinafter set forth in the various drawings and drawings.
These and other objects, features and advantages of the present invention will become more apparent from the following detailed description of one or more preferred embodiments of the invention, as illustrated in the accompanying drawings.
Drawings
The accompanying drawings, which are included to provide a further understanding of the invention and are incorporated in and constitute a part of this specification, illustrate embodiments of the invention and together with the description serve to explain the principles of the invention and not to limit the invention.
In the drawings, like parts are designated with like reference numerals, and the drawings are schematic and not necessarily drawn to scale.
In order to more clearly illustrate the embodiments or technical solutions in the prior art of the present invention, the drawings used in the description of the embodiments or prior art will be briefly described below, it is obvious that the drawings in the following description are only one or several embodiments of the present invention, and for those skilled in the art, other drawings can be obtained according to such drawings without creative efforts.
FIG. 1 is a system block diagram of the present invention.
FIG. 2 is a flow diagram of a visitor in the present invention.
Detailed Description
The following detailed description of the embodiments of the present invention will be provided with reference to the drawings and examples, so that how to apply the technical means to solve the technical problems and achieve the technical effects can be fully understood and implemented. It should be noted that, as long as there is no conflict, the embodiments and the features of the embodiments of the present invention may be combined with each other, and the technical solutions formed are within the scope of the present invention.
In the following description, for purposes of explanation, numerous specific details are set forth in order to provide a thorough understanding of the embodiments of the invention. It will be apparent, however, to one skilled in the art that the present invention may be practiced without some of these specific details or with other methods described herein.
Referring to fig. 1-2, in the embodiment of the invention, a comprehensive management system for intelligent access control based on 5G internet of things and AI comprises an intelligent access control terminal and a function module connected with the intelligent access control terminal through a 5G internet of things technology;
the functional module comprises an access control management unit which is used for limiting personnel to enter and exit;
an authorization management unit: the system comprises a door control management unit, a door control management unit and a door control unit, wherein the door control management unit is used for sending an authorization instruction sent by an owner to the door control management unit;
building management unit: the system is used for acquiring personnel arrangement information and personnel identity information inside the building;
a personnel management unit: the system is used for acquiring the in-out time, the staying time and the business handling information of the personnel in the building;
visitor management unit: the system comprises a visitor, a client and a system server, wherein the visitor is used for receiving instruction information input by the visitor, auditing the information and sending the information to the owner;
a positioning navigation unit: the system comprises a target path providing unit, a target path providing unit and a target path providing unit, wherein the target path is used for providing a user to obtain an authorization management unit;
the positioning navigation unit is used for receiving the access address sent by the visitor management unit, calling a building map and presenting a path indication map to the visitor handheld terminal by combining the AR technical block.
The entrance guard management unit comprises a face recognition block, a voice recognition block, a fingerprint recognition block and a label recognition block, wherein the face recognition block, the voice recognition block, the fingerprint recognition block and the label recognition block are used for recognizing visitors.
The personnel management unit comprises a marking block for intelligently marking different personnel identities and an alarm block for counting the access time of different personnel and giving an alarm according to the access time of the personnel with different identities, the alarm block is used for prompting the old in a management personnel cell to be inactive for a long time, accidents can occur, and theft and other things can occur when the access time of external personnel is too long.
The authorization management unit comprises an invitation block which is convenient for a business owner to send an invitation command to the intelligent access control terminal, and the invitation block comprises visitor photo information, frequent place information and visiting time information.
The building management unit comprises a camera block used for acquiring video information inside the building.
The embodiment of the invention provides a 5G-based intelligent access control management system, which comprises access entrances of a plurality of terminals such as a PC (personal computer) terminal, a mobile APP (application), a WeChat applet and the like, provides different access contents for owners, managers and visitors, and comprises main functional modules of the system, such as access control management, authorization management, building management, house management, personnel management, visitor management, personnel control management, visitor record management, GIS (geographic information system) navigation, VR (virtual reality) scene positioning navigation and the like.
The system can be used for integrated management of a plurality of terminal accesses such as hall access control, floor access control, room access control and the like through access control management. The front-end intelligent entrance guard controller that adopts removes the thing networking through 5G, and the mounting means is very simple, and the networking is fast stability good, supports multiple AI intelligent recognition technologies such as face identification, password identification, fingerprint identification. The front-end access control equipment is mainly used for authorized matching of data information of access personnel, calculation, matching and reporting of edges of deployment and control personnel and the like.
The system integrates management of physical information of buildings, houses, personnel and the like, for example, information of a certain building, a certain floor, owners and family members of a certain household, or owners and staff in a plurality of rooms in a garden, a certain building, a certain floor and a plurality of rooms in the community is comprehensively managed, and managers can find out which information is input or imported into the system. Through the binding association configuration of the information and the access control equipment, the access control authorization schemes of different personnel and areas in a scene can be configured more intelligently and efficiently.
The system provides a two-way visitor visit management mode in the aspect of visitor visit management, namely a visitor initiative reservation application mode and an owner initiative invitation mode, visitors can make visit reservation according to a mobile APP, a WeChat applet or a PC terminal provided by the system, and after a pending business owner checks the visit, the system applies for notification, specific position information, time and navigation link to visitor users in message modes such as short messages and WeChat. Meanwhile, time and data information such as the face and the password of a visitor are sent to a certain room entrance guard belonging to a related public area such as a residential quarter entrance guard, a building entrance guard, a floor entrance guard and a private area such as a proprietor, the visitor can smoothly enter the visiting proprietor according to link navigation and specified time, after a map navigation mode based on a 2D (two-dimensional), 3D (three-dimensional) or satellite mode is provided for an outdoor area system to enter an indoor area, the system can be automatically switched into an AR (augmented reality) scene navigation mode according to positioning information, and a visitor user can quickly and accurately find a line position through the navigation. The owner can operate on a mobile terminal, a WeChat small program or a PC terminal of the system to add visitor information and invitation information, the system can automatically push related information to visitors, and the visiting flow of the system is consistent with the visitor reservation application.
The system provides a function of marking labels and a function of arranging and controlling the labels for personnel, and a personnel label system under a use scene can be established through personnel management and label management of the system. Such as personnel tags for owners, family members, the elderly, children, express delivery personnel, cleaning personnel, and the like. According to the personnel deployment and control management configuration, different deployment and control requirements can be configured for a certain person or a certain class of people, such as the deployment and control of express delivery personnel and the deployment and control of district teaching and modifying personnel, and all-weather or specific time and frequency deployment and control requirements can be carried out. And when the corresponding tag personnel pass through the entrance guard, the entrance guard equipment reports the collected data after matching. The managers can quickly track and position the access records, tracks and the like of the control personnel, so that the management is more intelligent, and the management efficiency is effectively improved.
The use and implementation of the invention comprises the following steps:
firstly, installing and networking access control equipment, and adding system access control equipment;
and step two, binding the buildings, the units and the houses with personnel and associations, and associating the access control equipment with the buildings, the units and the houses.
Thirdly, the administrator searches the associated access control equipment through the internal personnel and issues access control passing authorization data; the visitor makes a reservation application through a mobile APP, a WeChat applet or a PC (personal computer) terminal of the login system, the owner can also check reservation information of the visitor through each access terminal, and the system pushes a check result to the visitor through message modes such as WeChat and short message. If the verification is not passed, prompting that the verification application fails, and if the verification application passes, prompting that the application is successfully submitted and the visit time, the detailed address and the navigation link are successfully submitted; and meanwhile, sending visitor access information to the associated access control data.
The owner can log in at each access terminal to fill in and initiate an invitation application. The system pushes invitation visit time, detailed addresses and navigation links to visitors in a WeChat and short message mode according to the invitation contents, and meanwhile, sends visitor access information to the associated access control data.
And step four, setting different personnel labels by the administrator through system label management, and marking the personnel according to different identities and types such as owners, children, old people, express delivery, food delivery, cleaning and the like.
Step five, a system administrator guides the intelligent entrance guard system to intelligently learn and analyze through an image AI recognition algorithm, such as the analysis and recognition of data of clothes color, clothes marks, hat color and the like, and establishes different identity character model libraries;
the system extracts the target person in the snapshot image by using a background difference technology, and then solves the problems of non-linearity, high-dimensional and small sample learning by using a characteristic-based vector machine mode identification algorithm, thereby improving the expansibility and the resolution of the algorithm. The algorithm analysis is carried out according to five steps of target acquisition, image processing, feature extraction and surface feature classification, wherein the target acquisition acquires geometric features of a connected region through image scanning, including a minimum circumscribed rectangle, an area, a mass center and the like. The target area parameter M (m) can be used as a metric, and for the area A (x, y), M (m) is defined as the number of pixels in the area, i.e. the area
Then according to the position of the target area, the centroid is taken as the measurement size, the target centroid is set as (Cx, Cy),
Cx＝M10(Ai(x,y))/M00(Ai(x,y))
Cy＝M01(Ai(x,y))/M00(Ai(x,y))
wherein the matrix is defined as:
the positions of the extreme points of the boundary outline of the target circumscribed rectangle, including the upper (t), the lower (b), the left (l) and the right (r), are calculated as follows:
the feature extraction follows image normalization; converting and quantizing the color space to obtain a color vector; for each block, the color or contour value is extracted, the formula is as follows:
the table feature classification calculation uses SVM to solve the multi-class classification problem, and uses fi(x) The i-1, 2, a, N function tests an arbitrary sample x of the image N for its class Gx as calculated by the following function:
and finally, judging whether a certain sample x belongs to the class c, firstly calculating z as phi (x), and then calculating the following decision function:
if f (z) is 1, x belongs to class c, otherwise it does not.
Step six, a system administrator performs control on specific personnel or personnel with specific identity types through control management setting, sets control rule setting, such as management and control of access interval duration of couriers, absence of early warning for the old over 5 days and the like;
step seven, the entrance guard matches through the input fingerprint of the visit personnel, password or human face data gathered, forbid entering if matching is unsuccessful, carry on the practical analysis matching if matching is successful; if the time matching is unsuccessful, the access is forbidden, if the time matching is successful, the intelligent access control is performed by the synchronous cloud server, the personnel is analyzed and judged whether the personnel is in the control range, if the personnel is not in the control range, the access is directly allowed, if the personnel is in the control range, a corresponding control rule scheme is started, and if the personnel is in the control range, the access time length of express personnel and the access control track are tracked and calculated;
and step eight, the intelligent access control intelligently judges the path track through personnel identity recognition, prompts the next access control path direction on an access control display screen, and provides VR virtual scene positioning navigation, so that visitors can conveniently and quickly find the accurate path. In the system, VR path navigation is optimized by calculation based on an A-x algorithm, and a calculation function formula is as follows:
cost(n)＝g(n)
f(n)＝g(n)+h(n)
where g (n) represents the back-off cost of the current node, h (n) represents the forward cost of the current node, but more people say h (n) is a heuristic function. And f (n) on the right is called the merit function. The distance path calculation is calculated by using a Manhattan distance calculation method according to the following function formula:
D(N1,N2)＝|N1x-N2x|+|N1y-N2y|
because the manhattan distance satisfies the consistency and the characteristic of "h (gold) ═ 0", the calculation cost is low, and the calculation is simple and efficient.
Step nine, visitors enter a room through an entrance guard under the guidance of the entrance guard and an intelligent entrance guard, monitoring and tracking the personnel in the control range and the cloud background system continuously, if the visitors do not leave the room after the set time, starting the system to automatically send an early warning message to a manager, wherein the message content comprises the picture of the visitors, the current room position, the entering time and the stay overtime, and the manager can conveniently and quickly position, investigate and process the visitors;
step ten, after the visit of the visitor is finished, after the visitor leaves the house, if the visitor leaves the house, the visitor does not leave the district beyond the set time, the system automatically pushes alarm information to the manager and the visited owner, the information content comprises the image of the visitor, the current position, the entering time and the last entrance guard time, the manager can rapidly send security personnel to go to the investigation and disposal, illegal and malicious commander of the person is effectively prevented, the system automatically exports one by one according to the tracking until the entrance guard person leaves the district range, the visitor leaves the message to the manager and the visited owner automatically, and meanwhile, the system automatically sends an instruction to each associated intelligent entrance guard terminal to delete the visit authorization of the visitor.
It will be evident to those skilled in the art that the invention is not limited to the details of the foregoing illustrative embodiments, and that the present invention may be embodied in other specific forms without departing from the spirit or essential attributes thereof. The present embodiments are therefore to be considered in all respects as illustrative and not restrictive, the scope of the invention being indicated by the appended claims rather than by the foregoing description, and all changes which come within the meaning and range of equivalency of the claims are therefore intended to be embraced therein. Any reference sign in a claim should not be construed as limiting the claim concerned.
Furthermore, it should be understood that although the present description refers to embodiments, not every embodiment may contain only a single embodiment, and such description is for clarity only, and those skilled in the art should integrate the description, and the embodiments may be combined as appropriate to form other embodiments understood by those skilled in the art.
Claims (8)
1. A comprehensive management system based on a 5G Internet of things and AI intelligent access control is characterized by comprising an intelligent access control terminal and a function module connected with the intelligent access control terminal through a 5G Internet of things technology;
the functional module comprises an access control management unit which is used for limiting personnel to enter and exit;
an authorization management unit: the system comprises a door control management unit, a door control management unit and a door control unit, wherein the door control management unit is used for sending an authorization instruction sent by an owner to the door control management unit;
building management unit: the system is used for acquiring personnel arrangement information and personnel identity information inside the building;
a personnel management unit: the system is used for acquiring the in-out time, the staying time and the business handling information of the personnel in the building;
visitor management unit: the system comprises a visitor, a client and a system server, wherein the visitor is used for receiving instruction information input by the visitor, auditing the information and sending the information to the owner;
a positioning navigation unit: for providing a target path to the entrance of the authorized management unit.
2. The integrated management system for 5G Internet of things and AI intelligent access control based on claim 1 is characterized in that the positioning navigation unit is used for receiving the access address sent by the visitor management unit, calling a building map and presenting a path indication map to the visitor handheld terminal in combination with an AR technical block.
3. The integrated management system for 5G Internet of things and AI intelligent access control based on claim 1, wherein the access control management unit comprises inside a face recognition block, a voice recognition block, a fingerprint recognition block and a tag recognition block for recognizing the visitor.
4. The integrated management system for the 5G Internet of things and AI intelligent access control based on the claim 1 is characterized in that the personnel management unit comprises a marking block for intelligently marking different personnel identities and an alarm block for counting the access time of different personnel and giving an alarm according to the access time of the personnel with different identities, the alarm block is used for prompting the old people in the management personnel community to be inactive for a long time, accidents can happen, and theft and the like can happen when the access time of external personnel is too long.
5. The integrated management system for 5G Internet of things and AI smart gates according to claim 1, wherein the authorization management unit comprises an invitation block for the owner to send an invitation command to the smart gate terminal, the invitation block comprising visitor photo information, frequent place information and visiting time information.
6. The integrated management system for 5G Internet of things and AI based intelligent entrance guard according to claim 1, wherein the building management unit comprises a camera block for obtaining video information inside the building.
7. The integrated management system for 5G Internet of things and AI intelligent access control based on claim 3, wherein the recognition algorithm of the face recognition block, such as the analysis and recognition of the data of clothes color, clothes mark and hat color, guides the intelligent learning analysis of the intelligent access control system, establishes different identity character model libraries, and the algorithm analysis is performed according to five steps of target acquisition, image processing, feature extraction and table feature classification, wherein the target acquisition acquires geometric features of a connected region through image scanning, including minimum bounding rectangles, area and centroid, and a target region area parameter M (m) can be used as a measurement scale, and for a region A (x, y), M (m) is defined as the number of pixels in the region, namely:
then according to the position of the target area, the centroid is taken as the measurement size, the target centroid is set as (Cx, Cy),
Cx＝M10(Ai(x,y))/M00(Ai(x,y))
Cy＝M01(Ai(x,y))/M00(Ai(x,y))
wherein the matrix is defined as:
the positions of the extreme points of the boundary outline of the target circumscribed rectangle, including the upper (t), the lower (b), the left (l) and the right (r), are calculated as follows:
the feature extraction follows image normalization; converting and quantizing the color space to obtain a color vector; for each block, the color or contour value is extracted, the formula is as follows:
the table feature classification calculation uses SVM to solve the multi-class classification problem, and uses fi(x) The i-1, 2, a, N function tests an arbitrary sample x of the image N for its class Gx as calculated by the following function:
and finally, judging whether a certain sample x belongs to the class c, firstly calculating z as phi (x), and then calculating the following decision function:
if f (z) is 1, x belongs to class c, otherwise it does not.
8. The integrated management system for 5G-based Internet of things and AI (intelligent access control) based on claim 2, wherein the AR technology block path navigation uses A-algorithm-based calculation optimization, and the calculation function formula is as follows:
cost(n)＝g(n)
f(n)＝g(n)+h(n)
where g (n) represents the back cost of the current node, h (n) represents the forward cost of the current node, but more people refer to h (n) as a heuristic function, and f (n) on the right is referred to as an evaluation function, the distance path calculation is calculated by using a manhattan distance calculation method, as follows:
D(N1,N2)＝|N1x-N2x|+|N1y-N2y|
because the manhattan distance satisfies the consistency and the characteristic of "h (gold) ═ 0", the calculation cost is low, and the calculation is simple and efficient.
Priority Applications (2)
| Application Number | Priority Date | Filing Date | Title |
|---|---|---|---|
| CN202011421723.0A CN112562161A (en) | 2020-12-08 | 2020-12-08 | Based on 5G thing networking and AI intelligent entrance guard integrated management system |
| PCT/CN2020/142561 WO2022121059A1 (en) | 2020-12-08 | 2020-12-31 | Intelligent integrated access control management system based on 5g internet of things and ai |
Applications Claiming Priority (1)
| Application Number | Priority Date | Filing Date | Title |
|---|---|---|---|
| CN202011421723.0A CN112562161A (en) | 2020-12-08 | 2020-12-08 | Based on 5G thing networking and AI intelligent entrance guard integrated management system |
Publications (1)
| Publication Number | Publication Date |
|---|---|
| CN112562161A true CN112562161A (en) | 2021-03-26 |
Family
ID=75059410
Family Applications (1)
| Application Number | Title | Priority Date | Filing Date |
|---|---|---|---|
| CN202011421723.0A Pending CN112562161A (en) | 2020-12-08 | 2020-12-08 | Based on 5G thing networking and AI intelligent entrance guard integrated management system |
Country Status (2)
| Country | Link |
|---|---|
| CN (1) | CN112562161A (en) |
| WO (1) | WO2022121059A1 (en) |
Cited By (15)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| CN113159632A (en) * | 2021-05-06 | 2021-07-23 | 重庆国科应用技术研究所有限公司 | Building management method and system based on user portrait |
| CN113762425A (en) * | 2021-11-09 | 2021-12-07 | 天津创启投资有限公司 | Data screen display sliding door control system based on 5G intelligent space |
| CN113791408A (en) * | 2021-08-24 | 2021-12-14 | 上海商汤智能科技有限公司 | Method, apparatus and storage medium for indoor positioning of target object |
| CN114499631A (en) * | 2021-12-29 | 2022-05-13 | 航天行云科技有限公司 | Method for determining optimal communication position of Internet of things terminal in scene of satellite Internet of things |
| CN114639188A (en) * | 2022-03-15 | 2022-06-17 | 云屏数字科技(云南)有限公司 | A WeChat-based visitor access control system and visitor door opening method |
| CN114743300A (en) * | 2021-12-09 | 2022-07-12 | 全民认证科技（杭州）有限公司 | Access control method and system for access control based on behavioral big data model |
| CN115273315A (en) * | 2022-06-22 | 2022-11-01 | 中银金融科技有限公司 | Nucleic acid detection queuing method, device and electronic equipment |
| CN115830760A (en) * | 2022-11-14 | 2023-03-21 | 点都互联科技有限公司 | Visitor management system based on intelligent access control |
| CN115909581A (en) * | 2022-11-07 | 2023-04-04 | 万申科技股份有限公司 | A data acquisition and processing system based on 5G Internet of Things |
| CN115953867A (en) * | 2023-01-09 | 2023-04-11 | 江苏信江数字科技有限公司 | Smart city management data processing method and system |
| CN116820183A (en) * | 2023-08-31 | 2023-09-29 | 泉州昆泰芯微电子科技有限公司 | Knobs and electrical appliances with rotary feedback |
| CN116820160A (en) * | 2023-08-29 | 2023-09-29 | 绵阳光耀新材料有限责任公司 | Spheroidizing machine parameter regulation and control method and system based on glass bead state monitoring |
| CN117764562A (en) * | 2024-02-21 | 2024-03-26 | 瀚越智能科技(深圳)有限公司 | Intelligent management method and system for access control equipment based on Internet of Things |
| CN118470843A (en) * | 2024-07-12 | 2024-08-09 | 本溪钢铁（集团）信息自动化有限责任公司 | Multi-gate pass control method based on cloud edge |
| CN118762428A (en) * | 2024-07-19 | 2024-10-11 | 深圳零匙科技有限公司 | A joint control management method and system for smart locks |
Families Citing this family (17)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| CN115242840B (en) * | 2022-07-22 | 2024-06-11 | 北京住总集团有限责任公司 | Near zero energy consumption building operation maintenance management system and method based on Internet of things architecture |
| CN115273314B (en) * | 2022-07-22 | 2023-10-24 | 常州利明屏蔽有限公司 | Linkage control system for shelter shielding door |
| CN115123892B (en) * | 2022-07-27 | 2023-09-12 | 江苏飞耐科技有限公司 | Intelligent passenger judging reception method and system for elevator |
| CN115108419B (en) * | 2022-08-26 | 2023-01-06 | 中国工业互联网研究院 | Smart park multi-energy collaborative management and control method, device, equipment and storage medium |
| CN115345528A (en) * | 2022-10-18 | 2022-11-15 | 烟台东方智能技术有限公司 | Intelligent data management system for intelligent building |
| CN116152972A (en) * | 2022-11-03 | 2023-05-23 | 厦门烟草工业有限责任公司 | Access control management system, method and storage medium |
| CN115980062B (en) * | 2022-12-30 | 2024-09-17 | 南通诚友信息技术有限公司 | 5G-based industrial production line whole-process vision inspection method |
| CN116434388A (en) * | 2023-02-24 | 2023-07-14 | 黄山美润电子技术有限公司 | Building site security access control management system based on feature recognition |
| CN116011705B (en) * | 2023-03-27 | 2023-06-30 | 合肥坤语智能科技有限公司 | Hotel check-in intelligent management platform based on Internet of things |
| CN116229619B (en) * | 2023-05-09 | 2023-08-15 | 合肥坤语智能科技有限公司 | Intelligent door lock based on intelligent door magnetic induction system |
| CN116546438B (en) * | 2023-07-06 | 2023-09-15 | 宽兆科技(深圳)有限公司 | Building monitoring system based on Bluetooth MESH network |
| CN116956960B (en) * | 2023-07-28 | 2024-07-05 | 武汉市万睿数字运营有限公司 | Community visitor visit path restoration method and system based on cloud edge end collaboration |
| CN117408659B (en) * | 2023-10-27 | 2025-01-24 | 西安秦创智谷孵化器有限公司 | An ERP enterprise management system |
| CN117830960B (en) * | 2024-03-05 | 2024-05-14 | 毕昇云(武汉)信息技术有限公司 | A risk identification method, device, equipment and medium based on smart community |
| CN117931846B (en) * | 2024-03-22 | 2024-05-24 | 瀚越智能科技(深圳)有限公司 | Intelligent access control data management method and system based on multi-source fusion |
| CN118365141A (en) * | 2024-06-18 | 2024-07-19 | 湘江实验室 | Building security risk prediction method, device, terminal equipment and medium |
| CN119992702A (en) * | 2025-04-16 | 2025-05-13 | 深圳市澜潮科技有限公司 | Building intelligent management method and system based on artificial intelligence |
Citations (7)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| CN102663409A (en) * | 2012-02-28 | 2012-09-12 | 西安电子科技大学 | Pedestrian tracking method based on HOG-LBP |
| CN105761339A (en) * | 2016-01-29 | 2016-07-13 | 成都比善科技开发有限公司 | Community access control system and method |
| CN109003372A (en) * | 2018-08-19 | 2018-12-14 | 天津新泰基业电子股份有限公司 | A kind of caller management method and system based on cloud |
| CN109240288A (en) * | 2018-08-31 | 2019-01-18 | 武汉理工大学 | Unmanned boat collision prevention paths planning method in the case of a kind of barrier based on trajectory unit |
| CN110009784A (en) * | 2019-04-02 | 2019-07-12 | 深圳市万物云科技有限公司 | Monitoring joint defence method and apparatus and system and storage medium based on artificial intelligence |
| CN110009543A (en) * | 2019-04-02 | 2019-07-12 | 深圳市万物云科技有限公司 | Based on artificial intelligence community access control management method and device and system and storage medium |
| CN110415420A (en) * | 2019-08-22 | 2019-11-05 | 广东鉴面智能科技有限公司 | A kind of visitor's intelligent management system and its management method based on recognition of face |
Family Cites Families (4)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| US6192314B1 (en) * | 1998-03-25 | 2001-02-20 | Navigation Technologies Corp. | Method and system for route calculation in a navigation application |
| CN106327619A (en) * | 2015-06-24 | 2017-01-11 | 北大方正集团有限公司 | In/out management method and system thereof |
| CN106485202A (en) * | 2016-09-18 | 2017-03-08 | 南京工程学院 | Unconfinement face identification system and method |
| CN108225326A (en) * | 2017-12-31 | 2018-06-29 | 南京理工大学 | A kind of AGV paths planning methods based on A* algorithms |
-
2020
- 2020-12-08 CN CN202011421723.0A patent/CN112562161A/en active Pending
- 2020-12-31 WO PCT/CN2020/142561 patent/WO2022121059A1/en not_active Ceased
Patent Citations (7)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| CN102663409A (en) * | 2012-02-28 | 2012-09-12 | 西安电子科技大学 | Pedestrian tracking method based on HOG-LBP |
| CN105761339A (en) * | 2016-01-29 | 2016-07-13 | 成都比善科技开发有限公司 | Community access control system and method |
| CN109003372A (en) * | 2018-08-19 | 2018-12-14 | 天津新泰基业电子股份有限公司 | A kind of caller management method and system based on cloud |
| CN109240288A (en) * | 2018-08-31 | 2019-01-18 | 武汉理工大学 | Unmanned boat collision prevention paths planning method in the case of a kind of barrier based on trajectory unit |
| CN110009784A (en) * | 2019-04-02 | 2019-07-12 | 深圳市万物云科技有限公司 | Monitoring joint defence method and apparatus and system and storage medium based on artificial intelligence |
| CN110009543A (en) * | 2019-04-02 | 2019-07-12 | 深圳市万物云科技有限公司 | Based on artificial intelligence community access control management method and device and system and storage medium |
| CN110415420A (en) * | 2019-08-22 | 2019-11-05 | 广东鉴面智能科技有限公司 | A kind of visitor's intelligent management system and its management method based on recognition of face |
Cited By (20)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| CN113159632A (en) * | 2021-05-06 | 2021-07-23 | 重庆国科应用技术研究所有限公司 | Building management method and system based on user portrait |
| CN113791408A (en) * | 2021-08-24 | 2021-12-14 | 上海商汤智能科技有限公司 | Method, apparatus and storage medium for indoor positioning of target object |
| CN113791408B (en) * | 2021-08-24 | 2024-05-24 | 上海商汤智能科技有限公司 | Method, device and storage medium for indoor positioning target object |
| CN113762425A (en) * | 2021-11-09 | 2021-12-07 | 天津创启投资有限公司 | Data screen display sliding door control system based on 5G intelligent space |
| CN113762425B (en) * | 2021-11-09 | 2022-04-05 | 天津创启投资有限公司 | Data screen display sliding door control system based on 5G intelligent space |
| CN114743300A (en) * | 2021-12-09 | 2022-07-12 | 全民认证科技（杭州）有限公司 | Access control method and system for access control based on behavioral big data model |
| CN114499631B (en) * | 2021-12-29 | 2024-05-14 | 航天行云科技有限公司 | Optimal communication position determining method of Internet of things terminal in satellite Internet of things scene |
| CN114499631A (en) * | 2021-12-29 | 2022-05-13 | 航天行云科技有限公司 | Method for determining optimal communication position of Internet of things terminal in scene of satellite Internet of things |
| CN114639188A (en) * | 2022-03-15 | 2022-06-17 | 云屏数字科技(云南)有限公司 | A WeChat-based visitor access control system and visitor door opening method |
| CN115273315A (en) * | 2022-06-22 | 2022-11-01 | 中银金融科技有限公司 | Nucleic acid detection queuing method, device and electronic equipment |
| CN115909581A (en) * | 2022-11-07 | 2023-04-04 | 万申科技股份有限公司 | A data acquisition and processing system based on 5G Internet of Things |
| CN115830760A (en) * | 2022-11-14 | 2023-03-21 | 点都互联科技有限公司 | Visitor management system based on intelligent access control |
| CN115953867A (en) * | 2023-01-09 | 2023-04-11 | 江苏信江数字科技有限公司 | Smart city management data processing method and system |
| CN115953867B (en) * | 2023-01-09 | 2023-05-16 | 江苏信江数字科技有限公司 | Smart city management data processing method and system |
| CN116820160A (en) * | 2023-08-29 | 2023-09-29 | 绵阳光耀新材料有限责任公司 | Spheroidizing machine parameter regulation and control method and system based on glass bead state monitoring |
| CN116820183B (en) * | 2023-08-31 | 2023-12-08 | 泉州昆泰芯微电子科技有限公司 | Knob with rotary feedback sense and electric appliance |
| CN116820183A (en) * | 2023-08-31 | 2023-09-29 | 泉州昆泰芯微电子科技有限公司 | Knobs and electrical appliances with rotary feedback |
| CN117764562A (en) * | 2024-02-21 | 2024-03-26 | 瀚越智能科技(深圳)有限公司 | Intelligent management method and system for access control equipment based on Internet of Things |
| CN118470843A (en) * | 2024-07-12 | 2024-08-09 | 本溪钢铁（集团）信息自动化有限责任公司 | Multi-gate pass control method based on cloud edge |
| CN118762428A (en) * | 2024-07-19 | 2024-10-11 | 深圳零匙科技有限公司 | A joint control management method and system for smart locks |
Also Published As
| Publication number | Publication date |
|---|---|
| WO2022121059A1 (en) | 2022-06-16 |
Similar Documents
| Publication | Publication Date | Title |
|---|---|---|
| CN112562161A (en) | Based on 5G thing networking and AI intelligent entrance guard integrated management system | |
| US20250384115A1 (en) | System and method for provisioning a facial recognition-based system for controlling access to a building | |
| US12457218B2 (en) | Methods and system for distributed cameras and demographics analysis | |
| US10812761B2 (en) | Complex hardware-based system for video surveillance tracking | |
| KR102333143B1 (en) | System for providing people counting service | |
| CN109271554B (en) | Intelligent video identification system and application thereof | |
| CN109117745B (en) | Cloud face recognition and positioning method based on building information model | |
| US20190087464A1 (en) | Regional population management system and method | |
| WO2021188140A1 (en) | Available vehicle parking space detection using machine learning | |
| CN109903414A (en) | One kind is based on Internet of Things monitoring office attendance control system and method | |
| CN108269331A (en) | A kind of intelligent video big data processing system | |
| CN112738477A (en) | Security monitoring system | |
| CN114358980A (en) | Intelligent community property management system and method based on Internet of things | |
| CN110930577A (en) | Method for analyzing unregistered but actually living in personnel based on entrance guard data | |
| CN115761614A (en) | Abnormal behavior target detection system based on multi-view deep learning algorithm | |
| CN109582824A (en) | A kind of region security management system and method based on video structural | |
| CN108376237A (en) | A kind of house visiting management system and management method based on 3D identifications | |
| CN210515326U (en) | Scenic spot ticket inspection system based on face AI recognition | |
| CN114299448B (en) | A method and system for identifying the behavior of people illegally bringing mobile phones into sensitive places | |
| CN113158771B (en) | Community personnel information acquisition method, system and application | |
| CN113326747A (en) | Teaching worker face recognition attendance checking method and system | |
| CN113554794A (en) | Community permanent user and visitor access management system based on intelligent property | |
| CN113269916B (en) | Guest prejudging analysis method and system based on face recognition | |
| CN115083053A (en) | Intelligent community access control system and control method | |
| CN107798312A (en) | A kind of automatic Work attendance method of view-based access control model head detection |
Legal Events
| Date | Code | Title | Description |
|---|---|---|---|
| PB01 | Publication | ||
| PB01 | Publication | ||
| SE01 | Entry into force of request for substantive examination | ||
| SE01 | Entry into force of request for substantive examination | ||
| RJ01 | Rejection of invention patent application after publication | ||
| RJ01 | Rejection of invention patent application after publication |
Application publication date: 20210326 |
