CN110908705B

CN110908705B - Method for Establishing Mapping Relationship of Program Class Collections of Different Versions

Info

Publication number: CN110908705B
Application number: CN201911138413.5A
Authority: CN
Inventors: 陈星�; 陈晓娜; 胡传淑敏; 郭莹楠; 陈艳
Original assignee: Fuzhou University
Current assignee: Fuzhou University
Priority date: 2019-11-20
Filing date: 2019-11-20
Publication date: 2021-06-22
Anticipated expiration: 2039-11-20
Also published as: CN110908705A

Abstract

The present invention proposes a method for establishing a mapping relationship between classes of different versions of a program. First, the judging factors for class similarity and method similarity are determined; secondly, a class diagram is established from source code reverse engineering; finally, a series of algorithm analysis (including calculation Preliminary class similarity, method similarity, and iteratively establish the final similarity of methods and classes) to establish the "one-to-one", "one-to-many" and "many-to-one" mapping relationships of classes in the class set of programs between different versions And a "one-to-one" mapping of methods in a class. It can solve the problem that it is difficult to find the mapping relationship between different version system class sets due to manual reading of the source code, etc. It can directly reflect the system architecture, increase the readability and maintainability of the code, and reduce software developers and maintainers. Understanding the difficulty of systems across versions provides a way to look at different systems at a high level.

Description

Method for establishing mapping relation of program class sets of different versions

Technical Field

The invention belongs to the technical field of computer software, and particularly relates to a method for establishing class set mapping relations of programs of different versions, particularly Java programs.

Background

Object-oriented technology has been a focus of research since its introduction. To date, object-oriented approaches have gradually penetrated various levels and aspects of software development, emerging as object-oriented approaches including object-oriented analysis, design, and programming. Software evolution refers to the process by which software is ramped and brought to a desired morphology. Software evolution plays an important role in prolonging the service life of software, the efficiency of software programs is improved after the software programs are evolved, and defects are corrected. Software maintenance and evolution are inevitable, but sometimes project personnel do not only want to obtain the evolved programs, and more, they desire to obtain the differences of the programs of different versions after the evolution. The evolution analysis of the software can help to comprehensively understand the program differences of different versions, the comprehensive understanding of the programs of the versions and the comprehensive understanding of the program differences of the different versions are the basis of program maintenance, however, the evolved programs have huge code quantity due to complex and linked structures, and the mode of analyzing the program evolution information by reading the source codes is a difficult and unwise behavior.

Although object-oriented technology has significantly improved the maintainability of programs, since the evolution analysis of different versions of programs at present needs to resort to development documents or change records of different versions of programs, the lack, incompleteness and inconsistency of normalized documents are common problems. Therefore, how to extract the high-level structure information of each version from the software programs of different versions under the condition of lacking of such documents is achieved, the mapping relation between the software programs of different versions is established according to the high-level structure information, and the difference between the software programs of different versions is obtained according to the mapping relation, so that the development of the high-level evolution information of the software programs becomes a troublesome problem in the software evolution analysis process.

Disclosure of Invention

In view of the deficiencies of the prior art, the technical problem to be solved by the present invention is to provide a method for establishing class set mapping relationships of different versions of programs, especially Java programs, wherein given two versions of source codes before and after the evolution of a Java program, the mapping relationships of "one-to-one", "one-to-many", "many-to-one" of classes in class sets of Java programs of old and new versions and the "one-to-one" mapping relationships of methods in method sets can be obtained.

In the scheme of the invention, firstly, judging factors of class similarity and method similarity are determined; secondly, establishing a class diagram from the reverse engineering of the source code, for example, analyzing the Java source code by a code analysis tool root to obtain an analyzed product, establishing models of classes in class sets of Java programs of different versions, and generating the class diagram; and finally, establishing the mapping relation of one-to-one, one-to-many and many-to-one of the classes in the class set of the Java program between different versions and the one-to-one mapping of the methods in the classes through a series of algorithm analysis (including calculating the initial class similarity, the method similarity and iteratively establishing the final similarity of the methods and the classes).

The method comprises the following specific steps:

a method for establishing a mapping relation of program class sets of different versions is characterized by comprising the following steps:

step S1: acquiring source codes of two different versions of the same program;

step S2: obtaining data structure information and the relation between classes and calling relation between methods in the classes according to the source codes of the two different versions in the step 1 through code analysis, and generating a class diagram;

step S3: calculating the primary class similarity: establishing model information of two version program class sets through the information obtained in the step S2, taking the class set of one version program as a class set A, calculating the similarity through a predefined class similarity evaluation factor, and determining the similarity of each class of the class set A under the class similarity evaluation factor of each class in a mapped version program class set B;

step S4: calculating the similarity of the method: establishing model information of two version method sets through the information obtained in the step S2, taking the method set of one version program as a method set A, calculating the similarity through a predefined method similarity evaluation factor, and determining the similarity of each method in a mapped version program method set B to each method in the method set A under the method similarity evaluation factor;

step S5: establishing a mapping relation: taking the method pair with the highest similarity, and establishing 'one-to-one' mapping of the methods; and according to the mapping relation of the method, adjusting the similarity of the classes in a step-by-step iteration mode, and finally determining the similarity between the classes.

Preferably, the program is a Java program.

Preferably, the class similarity evaluation factor includes: class name, attribute number, method number, similar attribute ratio and similar method ratio; the similarity evaluation factors of the method comprise: similarity between two classes to which the methods belong, frequency of calling the methods, frequency of calling other methods by the methods, method occupation ratio of mapping relations existing in a method set calling the two methods, and method occupation ratio and method signature of mapping relations existing in a method set called by the two methods.

Preferably, step S2 specifically includes:

step S21: definition of

Definition 1: CLASS set CLASS = { CLASS for a given program₁, Class₂, ..., Class_n }；

Wherein, Class_iIs the ith class of the program; represented as a triplet: class_i = < className, FIELD, METHOD >(ii) a className represents the name of the class, FIELD represents all attribute sets of the current class, and METHOD represents all METHOD sets of the current class;

definition 2: attribute set FIELD = { FIELD of any one class₁, Field₂, ..., Field_n }；

Wherein, the Filed_iIs the ith attribute of the current class; represented as a triplet: fieldi =< fieldModifier, fieldType, fieldName >The fieldModifier is the authority of the attribute, the fieldType is the type of the attribute, and the fieldName is the name of the attribute;

definition 3: METHOD set of any one class = { METHOD = { METHOD }₁, Method₂, ..., Method_n }；

Wherein, Method_iIs the ith method of the current class; represented as a quadruple: method for producing a metal oxide layer_i = < methodModifier, methodReturnType, methodName, METHODPARAM>Method modifier indicates method authority, method Return type indicates return value type of method, method name indicates name of method, METHODPARAM = { methodParam =₁, methodParam₂, ..., methodParam_nDenotes a parameter list set of the method, any one method param_jJ-th form showing the methodGinseng;

definition 4: similarity simClass = { sc) of new and old versions₁₁, sc₂₁, ..., sc_mn }；

Wherein, for any sc_ijStored in key-value pair format, with key format class_i .className<-> class_jclassName, corresponding to a class with a new version_iClass with old version_jThe similarity of (2);

definition 5: a method call Tree = (M, R) representing a call relationship of a method when a program runs, where M = { M = (M, R) }₁, m₂, ..., m_nR is the set of method nodes, and R is the set of method invocation edges; each edge r_ije.R represents a number from m_iTo m_jOf which the weight represents m_iCalling m_jThe frequency of (d); for arbitrary m_iIn presence of m_i.call_i = { call_i1, call_i2, ..., call_inDenotes calling m_iThe method set of (1); exist m_i.becall_i = { becall_i1, becall_i2, ..., becall_imDenotes m_iA set of methods to invoke;

definition 6: similarity simMETHOD = { sm) of new and old version methods₁₁, cm₂₁, ..., sm_mn }；

Wherein, for any sm_ijStoring in the form of key value pairs with a key format of m_i<-> m_jMethod m with a new version corresponding to the value_iMethod m with old version_jThe similarity of (2);

step S22: handling class names

I/define class Linked List

Chain<SootClass> classes = null;

V/load all classes, put class linked list classes = scene.v ().getapplicationclasses ();

// define class iterator

Iterator<SootClass> iterator = classes.iterator();

while(iterator.hasNext())

do{

SootClass = iterator

Class c_i= new ClassStructure (),/store in ClassStructure class form

String classname = SootClass

If the class is not the class of the analyzed Java program, then no record is made

if(!classname.contains(packagename)) continue;

c_i.className=classname;

}

setList(CLASS,c_i);

Step S23: handling attributes

Extracting attribute information for each class of a class set

for(c_i:CLASS){

V/define Attribute information iterator, load class Attribute information and traverse

Iterator<SootField> fieldIteratorerator = c_i.getFields().iterator();

while(fieldIteratorerator.hasNext())

do{

Sootfields = field

Stringname = s.getName (), attribute name type = s.getType (), toString (), attribute type int modifiers = s.getModifiers (), attribute rights ()

// return value 0: defaulting; returning the value 1: public; return value 2: a private; return value 4: protected

// store in the form of a FieldStructure class

Field f_ij = new FieldStructure();

f_ij.fieldModifiers=String.valueOf(modifiers); f_ij.fieldType=type; f_ij.fieldName=name; c_i.FIELD.add(f_ij) Storage of_iAttribute information of class }

}

Step S24: processing method

Extracting method information of each of class set/interface set

for(c_i:classlist||c_i:interfacelist){

I/define method information iterator, load class method information and traverse

Iterator<SootMethod> methodIterator = c_i.getMethods().iterator();

while(methodIterator.hasNext())

do{

Sootmethods = methoditerator. next (),/method information data structure

int modifiers = s.getModifiers (),/method permission Type = s.getTreturnType (),/Return Type

String name = s.getName (),/method name List < Type > paramTypes = s.getParameterTypes (),/parameter List

// store in the form of a method Structure class

Method m_ij = new MethodStructure(); m_ij.methodModifiers=String.valueOf(modifiers); m_ij.methodReturnType=String.valueOf(returntype); m_ij.methodName=name;

// parameters for the process should be stored separately

for(Type ttemp:paramTypes)

m_ij.METHODPARAM.add(String.valueOf(ttemp));

c_i.METHOD.add(m_ij) Storage of_iClass method information }

}

Step S25: handling inheritance relationships

// defining inheritance relationship storage Structure

List<String> entenders=new ArrayList<>();

// obtaining a parent class of a class

SootClass superclass = c_i.getSuperclass();

// Format: father-subclass

extenders.add(superclass.getName()+"<|--" + c_i.getName());

Step S26: processing implementation relationships

// define implementation relationship storage Structure

List<String> implements=new ArrayList<>();

Interface for obtaining certain class (class can realize multiple interfaces in Java program, Chain is adopted for storage)

Chain<SootClass> iChain = c_i.getInterfaces();

// generating iterator

Iterator<SootClass> iIterator = iChain.iterator();

while(iIterator .hasNext())

do{

SootClass interfaceclass = iIterator.next();

implememts.add(interfaceclass.getName()+"<|.." + c_i.getName());

}

Step S27: handling associative relations

// define association store Structure

List<SootClass> r11s= new ArrayList<>();

List<SootClass> r1ns =new ArrayList<>();

V/determining whether there is an association

if (c_i.Field_ik.fieldType.contains(packagename)) then

{

// determining whether or not it is 1 to many

if (c_i.Field_ik.fieldType.contains("[]"))

r1ns.add( c_i.getName() + "1--1..*" + fieldType);

else

r11s.add( c_i.getName() + "1--1" + fieldType);

}

Step S28: handling dependencies

// definition dependency storage architecture

List<String> relys=new ArrayList<>();

// obtaining dependencies

for(String s:method_invoke){

String uml= s.split("->")[0].split(":")[0]+" ..>"+s.split("->")[1].split(":")[0];

if（!relys.contain(uml)）then

relys.add(uml);

}

Step S29: handling call relation trees

The first step is as follows:

UL ij←U_ijgetvalue (),/DeU_ijThe left half of the ValueBox

UR ij←U_ijGetvalue (),/DeU_ijThe right half of the ValueBox

The second step is that:

if (U_ijgetClass () = = JAssignStmt) the// if an assignment statement

{

// Presence method Call

if ( UR ij.toString() == JSpecialInvokeExpr.class ||

UR ij.toString() == JVirturalInvokeExpr.class ||

UR ij.toString() == JInterfaceInvokeExpr.class ||

UR ij.toString() == JStaticInvokeExpr.class) then

{

// obtaining called method

invokeMethod<—U_ij.getMethod().getSignature();

invoke_k<—" M_i ->invokeMethod;/record call information

INVOKE.add(invoke_k);

}

else if (U_ijgetClass () = = JInvokeStmt) the// if call statement

{

if( U_ij.toString().contains(“specialinvoke”)||

U_ij.toString().contains(“virtualinvoke”)||

U_ij.toString().contains(“interfaceinvoke”)||

U_ij.toString().contains(“staticinvoke”)）then

{

// obtaining called method

invokeMethod<—U_ij.getMethod().getSignature();

invoke_k<—" M_i ->invokeMethod;/record call information

INVOKE.add(invoke_k);

}

The third step:

// construction InvokeTree

for(invoke_k:INVOKE)

1. Generate(invoke_k)。

Preferably, the step of calculating the similarity according to the predefined class similarity evaluation factor in step S3 specifically includes the following steps:

class_iAnd class_jClass name, attribute number, method number, similar attribute ratio, similar method ratio 5 judging factors for calculating class_iAnd class_jSimilarity of (2):

；

；

；

；

；

；

wherein, fnum_iIs class_iNumber of middle attributes, fnum_jIs class_jNumber of middle attributes, mnum_iIs class_iNumber of methods in (1), mnum_jIs class_jNumber of methods (1), fnum_ijIs class_iAnd class_jNumber of equal attributes in the set, mnum_ijIs class_iAnd class_jNumber of same methods in the same way.

Preferably, the step of calculating the similarity through the predefined method similarity evaluation factor in the step S4 specifically includes the following steps:

by the method m_iAnd m_jSimilarity between the two classes to which the method belongs, number of times the method is called, number of times the method calls other methods, call m_iM of the method set_iCall and call m_jM of the method set_jMethod contrast ratio, m, with a mapping relationship in call_iSet of called methods m_iBecall and m_jSet of called methods m_jMethod-to-contrast ratio and method signature 6 judgment factor calculation method m with mapping relationship in becall_iAnd m_jSimilarity of (2):

；

；

；

；

；

；

；

；

；

wherein becallm_ijIs m_iBecall and m_jThe number of pairs of methods having a mapping relationship in becall, becallnum_ijIs m_iBecall or m_jNumber of elements of bell, callm_ijIs m_iCall and m_jThe method for the existence of the mapping relation in the call is to the number, callnum_ijIs m_iCall or m_jThe number of elements of call.

Preferably, step S5 specifically includes:

the method pair with the highest similarity is selected, one-to-one mapping of the method is established, the similarity of the classes is adjusted step by step through the mapping relation of the method, the similarity between the classes is updated in a step-by-step iteration mode, when the mapping relation is determined by the last method, the similarity of the classes is finally determined, a threshold value is determined, the mapping relation of the classes is established, and the one-to-one mapping relation or the one-to-many mapping relation or the many-to-one mapping relation of the classes is finally obtained.

Preferably, step S5 is specifically realized by the following algorithm:

Data: number of methods in the new version：Nnum，number of methods in the old version：Onum, simCLASS, simMETHOD

Result: method mapping set methodMap, class mapping set classMap

while--Nnum>= 0 do

sm_ij = max{simMETHOD);

methodMap.put(method_i <—> method_j,sm_ij);

sc_ij=(sc_ij+ 1)/2;

for p in Nnum do

for q in Onum do

if method_i ∈method_p.call and method_j∈method_q,call then

callm_pq++

end

if method_i ∈method_p.becall and method_j∈method_q,becall then

becallm_pq++

end

update(simMETHOD)

end

if sc_ij>=0.8 then

classMap.put(class_i <—> class_j,sc_ij);

end。

the invention and its preferred embodiments have the following advantageous properties:

1. effectiveness: for different versions of source codes of a given Java program, the mapping relation, the similarity of classes, the mapping relation of methods and the mapping relation of class sets of the same class can be obtained.

2. The accuracy is as follows: for the calculated class similarity, obtaining class similarity by using class names, attribute numbers, method number attribute information and method information, wherein the similarity of classes with a certain mapping relation before and after evolution should have higher similarity, and the similarity of classes without the mapping relation should not be higher than the similarity between classes with the mapping relation; for the obtained method mapping relation, the found method one-to-one mapping relation is consistent with the mapping relation obtained by directly observing the source code; and for the obtained class set mapping relation, the found mapping relation is ensured to be consistent with the mapping relation obtained by directly observing the source code.

3. Universality: for given different Java programs, the mapping relation of the method and the mapping relation of the class set can be obtained.

The method comprises the steps of analyzing Java source codes through a code analysis tool root, obtaining analyzed products, establishing models of different types of classes in class sets of Java programs of different versions, then establishing one-to-one, one-to-many and many-to-one mapping relations of the classes in the class sets of the Java programs of the different versions through a series of operations, solving the problem that finding the mapping relations among the class sets of the systems of the different versions in a mode of manually reading the source codes and the like is difficult to implement, visually reflecting the system structure of the system, increasing the readability and maintainability of the codes, reducing the difficulty of software developers and maintainers in understanding the systems of the different versions, and providing a method for observing the systems of the different versions at a higher level.

Drawings

The invention is described in further detail below with reference to the following figures and detailed description:

FIG. 1 is a schematic overall flow diagram of an embodiment of the present invention;

FIG. 2 is a schematic diagram of a mapping algorithm according to an embodiment of the present invention;

FIG. 3 is a schematic view of a user input interface of an embodiment of the present invention;

FIG. 4 is a schematic diagram of an output of a version A class diagram of a car rental system for version evaluation according to an embodiment of the invention;

FIG. 5 is a schematic diagram of a version B class diagram output of a car rental system for version evaluation according to an embodiment of the present invention;

FIG. 6 is a diagram illustrating class mapping results according to an embodiment of the present invention

FIG. 7 is a diagram illustrating a mapping result according to an embodiment of the present invention.

Detailed Description

In order to make the features and advantages of the present invention comprehensible, embodiments accompanied with figures are described in detail as follows:

firstly, the implementation of the present embodiment takes the definition of the evaluation factor as the basis, including: and defining evaluation factors of class similarity and method similarity, such as class name, attribute number, attribute information, method number, method information, calling relationship, similarity between classes to which the methods belong, calling times of the methods, called times of the methods and the like.

As shown in fig. 1, the scheme flow provided by this embodiment includes the following steps:

step S1: acquiring source codes of two different versions of the same Java program; for example, given a typical object-oriented Java program, the Java program source code can be analyzed by the code analysis tool root;

step S2: analyzing data structure information in the root and calling logic information between classes corresponding to the Java program classes, wherein the data structure information comprises a class name list, a member variable table, a member method table, a parent class and an interface list. Wherein the member variable information includes: attribute name, type, permission information, whether it is declared in a class, etc.; the information of the member method includes: method name, parameter type list, return value type, authority information, and type for declaring the method; and meanwhile, acquiring static relations (including implementation relations, inheritance relations and association relations) between classes, calling relations (dependency relations) between methods and methods in the classes, and the like, and generating a class diagram through the acquired information.

Step S3: calculating the primary class similarity: establishing model information of two versions of Java program class sets through the information obtained in the step S2, taking the class set of one version of Java program as a class set A, calculating the similarity through predefined class similarity evaluation factors, and determining the similarity of a certain class B in the mapped version of Java program class set B to each class in the class set A under the class similarity evaluation factors;

step S4: calculating the similarity of the method: establishing model information of two version method sets through the information obtained in the step S2, taking a method set of one version Java program as a method set A, calculating similarity through a predefined method similarity evaluation factor, and determining the similarity of a certain method B in a method set B of the mapped version Java program to each method of the method set A under the method similarity evaluation factor;

step S5: the method pair with the highest similarity is taken, and the one-to-one mapping of the methods is established. The similarity of the classes is gradually adjusted through the mapping relation of the method, the similarity between the classes is finally determined through a gradual iteration mode, and finally three kinds of mapping relations of the classes are obtained.

Specifically, the specific implementation thereof comprises:

1 detailed construction of the protocol of this example

1.1 defining class similarity evaluation factor and method similarity evaluation factor

Definition class similarity evaluation factor

In this embodiment, 5 classes of static features are selected as the factors for class similarity evaluation, which are:

1. a class name; 2. the number of attributes; 3. the number of the methods; 4. similar attribute ratio; 5. similar methods are used.

(II) defining method similarity evaluation factor

In this embodiment, 4 pieces of information obtained by simulating system operation, static information (method signature) of the method, and similarity of the method category are selected as factors for judging similarity of the method. (We believe that the method should have only a "one-to-one" mapping)

1. Similarity between the two classes to which the method belongs; 2. the frequency at which the method is invoked; 3. the frequency with which the method calls other methods; 4. calling method contrast of mapping relation in method set of the two methods; 5. the method comparison of the mapping relation exists in the method set called by the two methods; 6. method signature (authority of method, return value type, method name, parameter list type of method).

1.2 obtaining information and generating class diagrams

1.2.1 Definitions

Definition 1: CLASS set CLASS = { CLASS for a given program₁, Class₂, ..., Class_n }。

Wherein, Class_iIs the ith class of programs, which can be represented as a triple: class_i = < className, FIELD, METHOD >. className represents the name of the class, FIELD represents the set of all the attributes of the current class, and METHOD represents the set of all the METHODs of the current class.

Definition 2: attribute set FIELD = { FIELD of any one class₁, Field₂, ..., Field_n }。

Wherein, the Filed_iIs the ith attribute of the current class, which can be represented as a triple: fieldi =< fieldModifier, fieldType, fieldName >The fieldModifier is the authority of the attribute, the fieldType is the type of the attribute, and the fieldName is the name of the attribute.

Definition 3: METHOD set of any one class = { METHOD = { METHOD }₁, Method₂, ..., Method_n }。

Wherein, Method_iThe ith method, which is a current class, can be represented as a quadruple: method for producing a metal oxide layer_i = < methodModifier, methodReturnType, methodName, METHODPARAM>Method modifier indicates method authority, method Return type indicates return value type of method, method name indicates name of method, METHODPARAM = { methodParam =₁, methodParam₂, ..., methodParam_nDenotes a parameter list set of the method, any one method param_jThe jth argument of the method is shown.

Definition 4: similarity simClass = { sc) of new and old versions₁₁, sc₂₁, ..., sc_mn }。

Wherein, for any sc_ijStoring in key-value pair format (key format class)_i .className<-> class_jclassName, corresponding to a class with a new version_iClass with old version_jSimilarity of (d).

Definition 5: method call Tree = (M, R), which represents the call relationship of the method when the system runs, where M = { M = (M, R) }₁, m₂, ..., m_nIs the set of method nodes, and R is the set of method call edges. Each edge r_ije.R represents a number from m_iTo m_jOf which the weight represents m_iCalling m_jOf (c) is detected. For arbitrary m_iIn presence of m_i.call_i = { call_i1, call_i2, ..., call_inDenotes calling m_iA method set of (1). Exist m_i.becall_i = { becall_i1, becall_i2, ..., becall_imDenotes m_iA set of methods to invoke.

Definition 6: similarity simMETHOD = { sm) of new and old version methods₁₁, cm₂₁, ..., sm_mn }。

Wherein, for any sm_ijStoring in key value pair form (key format is m)_i<-> m_jMethod m with a new version corresponding to the value_iMethod m with old version_jSimilarity of (d).

1.2.2 flow Steps

Class (I) name

I/define class Linked List

Chain<SootClass> classes = null;

// define class iterator

Iterator<SootClass> iterator = classes.iterator();

while(iterator.hasNext())

do{

SootClass = iterator

Class c_i= new ClassStructure (),/store in ClassStructure class form

String classname = SootClass

if(!classname.contains(packagename)) continue;

c_i.className=classname;

}

setList(CLASS,c_i);

(II) Properties

Extracting attribute information for each class of a class set

for(c_i:CLASS){

Iterator<SootField> fieldIteratorerator = c_i.getFields().iterator();

while(fieldIteratorerator.hasNext())

do{

Sootfields = field

// store in the form of a FieldStructure class

Field f_ij = new FieldStructure();

}

(III) method

Extracting method information of each of class set/interface set

for(c_i:classlist||c_i:interfacelist){

Iterator<SootMethod> methodIterator = c_i.getMethods().iterator();

while(methodIterator.hasNext())

do{

Sootmethods = methoditerator. next (),/method information data structure

// store in the form of a method Structure class

// parameters for the process should be stored separately

for(Type ttemp:paramTypes)

m_ij.METHODPARAM.add(String.valueOf(ttemp));

c_i.METHOD.add(m_ij) Storage of_iClass method information }

}

(IV) inheritance relationship

// defining inheritance relationship storage Structure

List<String> entenders=new ArrayList<>();

// obtaining a parent class of a class

SootClass superclass = c_i.getSuperclass();

// Format: father-subclass

extenders.add(superclass.getName()+"<|--" + c_i.getName());

(V) implementation relationship

// define implementation relationship storage Structure

List<String> implements=new ArrayList<>();

Chain<SootClass> iChain = c_i.getInterfaces();

// generating iterator

Iterator<SootClass> iIterator = iChain.iterator();

while(iIterator .hasNext())

do{

SootClass interfaceclass = iIterator.next();

implememts.add(interfaceclass.getName()+"<|.." + c_i.getName());

}

(VI) Association relationship

// define association store Structure

List<SootClass> r11s= new ArrayList<>();

List<SootClass> r1ns =new ArrayList<>();

V/determining whether there is an association

if (c_i.Field_ik.fieldType.contains(packagename)) then

{

// determining whether or not it is 1 to many

if (c_i.Field_ik.fieldType.contains("[]"))

r1ns.add( c_i.getName() + "1--1..*" + fieldType);

else

r11s.add( c_i.getName() + "1--1" + fieldType);

}

(VII) dependency relationship

// definition dependency storage architecture

List<String> relys=new ArrayList<>();

// obtaining dependencies

for(String s:method_invoke){

if（!relys.contain(uml)）then

relys.add(uml);

}

(eighth) calling relationship Tree

The first step is as follows:

UL ij←U_ijgetvalue (),/DeU_ijThe left half of the ValueBox

UR ij←U_ijGetvalue (),/DeU_ijThe right half of the ValueBox

The second step is that:

if (U_ijgetClass () = = JAssignStmt) the// if an assignment statement

{

// Presence method Call

if ( UR ij.toString() == JSpecialInvokeExpr.class ||

UR ij.toString() == JVirturalInvokeExpr.class ||

UR ij.toString() == JInterfaceInvokeExpr.class ||

UR ij.toString() == JStaticInvokeExpr.class) then

{

// obtaining called method

invokeMethod<—U_ij.getMethod().getSignature();

invoke_k<—" M_i ->invokeMethod;/record call information

INVOKE.add(invoke_k);

}

else if (U_ijgetClass () = = JInvokeStmt) the// if call statement

{

if( U_ij.toString().contains(“specialinvoke”)||

U_ij.toString().contains(“virtualinvoke”)||

U_ij.toString().contains(“interfaceinvoke”)||

U_ij.toString().contains(“staticinvoke”)）then

{

// obtaining called method

invokeMethod<—U_ij.getMethod().getSignature();

invoke_k<—" M_i ->invokeMethod;/record call information

INVOKE.add(invoke_k);

}

The third step:

// construction InvokeTree

for(invoke_k:INVOKE)

Generate(invoke_k)

1.3 calculate class similarity

；

；

；

；

；

；

1.4 method of calculating similarity

；

；

；

；

；

；

；

；

；

1.5 mapping Algorithm

The method pair with the highest similarity is taken, and the one-to-one mapping of the methods is established. The similarity of classes is gradually adjusted through the mapping relation of the methods, the similarity between the classes is updated through a gradual iteration mode, when the mapping relation is determined by the last method, the similarity of the classes is finally determined, a threshold value is determined, the mapping relation of the classes is established, and the one-to-one mapping relation, the one-to-many mapping relation and the one-to-many mapping relation of the classes are finally obtained. The specific mapping algorithm is shown in fig. 2.

2 mode of use

The scheme of the embodiment uses an integrated development tool IntelliJ IDEA, and is developed based on Java language.

(1) Before using the method of the embodiment, firstly, the method code is imported into the working interval: placing the two versions of system source code into the src directory as prompted by the user input interface in fig. 3, and modifying PACKAGENAME1 and PACKAGENAME2 of the user input interface according to the package name;

(2) and running the program under the condition of ensuring that no error exists in the first step, and automatically acquiring all relevant information by the method of the embodiment and generating the class diagrams of two versions. And simultaneously displaying the class set mapping relation and the method set mapping relation of the two versions.

3 test example

3.1 class diagram evaluation

Completeness: for a given Java program source code, information such as a class name, attribute authority, attribute type, attribute name, method authority, method return type, method name, method parameter list, class relationship (inheritance, implementation, association, dependency) and the like can be acquired.

Universality: the relevant information can be obtained for given different Java program source codes.

Two versions of a car rental system were used for evaluation, and the class diagram output is shown in fig. 4 and 5:

3.2 class Collection and method Collection mapping evaluation

Effectiveness: for different versions of source codes of a given Java program, the mapping relation, the similarity of classes, the mapping relation of methods and the mapping relation of class sets of the same class can be obtained.

The accuracy is as follows: for the calculated class similarity, obtaining class similarity by using class names, attribute numbers, method number attribute information and method information, wherein the similarity of classes with a certain mapping relation before and after evolution should have higher similarity, and the similarity of classes without the mapping relation should not be higher than the similarity between classes with the mapping relation; for the obtained method mapping relationship, it should be ensured that the found method one-to-one mapping relationship is consistent with the mapping relationship obtained by directly observing the source code; for the obtained class set mapping relationship, it should be ensured that the found mapping relationship is consistent with the mapping relationship obtained by directly observing the source code.

Universality: for given different Java programs, the mapping relation of the method and the mapping relation of the class set can be obtained.

The evaluation was performed using the two versions of the system described above, and the results are shown in fig. 6 and 7.

The obtained method mapping relation and the class set mapping relation are applied to the class diagram, the fact that the class diagram of the version 1 can be converted into the class diagram of the version 2 under the action of the mapping relation can be observed, meanwhile, the result of manually observing the source code is consistent with the result obtained by the method, and the limitation, the accuracy and the universality of the method can be met.

The present invention is not limited to the above preferred embodiments, and various other methods for creating the mapping relationship between different versions of program sets can be derived by anyone based on the teaching of the present invention.

Claims

1. a method for establishing different version program class set mapping relationship, is characterized in that, comprises the following steps:

Step S1: obtaining source codes of two different versions of the same program;

Step S2: According to the source codes of the two different versions of step 1, the data structure information, the relationship between classes and the classes, and the calling relationship between the methods in the classes are obtained through code analysis, and a class diagram is generated;

Step S3: Calculate the preliminary class similarity: establish model information of two version program class sets based on the information obtained in step S2, take the class set of one version program as the class set A, and calculate the similarity according to the predefined class similarity evaluation factors. degree, determine the similarity of each class in the mapped version program class set B to each class in the class set A under the class similarity evaluation factor;

Step S4: Calculate the similarity of the method: establish the model information of the two version method sets based on the information obtained in the step S2, take the method set of one version program as the method set A, and calculate the similarity through the predefined method similarity evaluation factors, Determine the similarity of each method in the method set B of the mapped version to each method in the method set A under the method similarity evaluation factor;

Step S5: Establish a mapping relationship: take the method pair with the highest similarity, and establish a "one-to-one" mapping of methods; according to the mapping relationship of the methods, adjust the similarity of the classes through a step-by-step iteration, and finally determine the similarity between the classes Spend;

The program is a Java program;

Step S2 specifically includes:

Step S21: Definition

Definition 1: The class set of a given program CLASS={Class ₁ , Class ₂ ,...,Class _n };

Among them, Class _i is the i-th class of the program; it is represented as a triple: Class _i =<className, FIELD,METHOD>; className represents the class name, FIELD represents the set of all attributes of the current class, and METHOD represents all the methods of the current class gather;

Definition 2: The attribute set of any class FIELD={Field ₁ , Field ₂ ,..., Field _n };

Among them, Filed _i is the ith attribute of the current class; it is represented as a triple: Fieldi=<fieldModifier, fieldType, fieldName>, fieldModifier is the permission of the attribute, fieldType is the type of the attribute, and fieldName is the name of the attribute;

Definition 3: Method set of any class METHOD={Method ₁ ,Method ₂ ,...,Method _n };

Among them, Method _i is the ith method of the current class; it is represented as a four-tuple: Method _i =<methodModifier, methodReturnType, methodName, METHODPARAM>, methodModifier represents the method authority, methodReturnType represents the return value type of the method, and methodName represents the method's Name, METHODPARAM={methodParam ₁ , methodParam ₂ ,..., methodParam _n } represents the parameter list set of the method, any methodParam _j represents the jth formal parameter of the method;

Definition 4: Class similarity between old and new versions simCLASS={sc ₁₁ ,sc ₂₁ ,...,sc _mn };

Wherein, for any sc _ij stored in the form of key-value pairs, the key format is class _i.className <->class _j.className , and the corresponding value is the similarity between the new version of class class _i and the old version of class class _j ;

Definition 5: Method call tree Tree=(M, R), which represents the calling relationship of methods when the program is running, where M={m ₁ , m ₂ ,..., m _n } is the method node set, and R is the method call edge The set of ; each edge r _ij ∈ R represents a method call from m _i to m _j , and its weight represents the frequency of m _i calling m _j ; for any m _i , there is m _i .call _i ={call _i1 ,call _i2 ,...,call _in } represents the method set for calling _{mi; there exists m i} _.becall _i ={becall _i1 ,becall _i2 ,...,becall _im } represents the method set called by _mi ;

Definition 6: Similarity of old and new versions of methods simMETHOD={sm ₁₁ , cm ₂₁ ,..., sm _mn };

Among them, for any sm _ij stored in the form of a key-value pair, the key format is m _i <-> m _j , and the corresponding value is the similarity between the method m _{i of the new version and the method m j} _of the old version;

Step S22: Process the class name, including:

define a linked list of classes;

Load all classes and put them into the class list;

Define class iterators, including:

Get the class data structure SootClass;

get class name;

If the class is not the class of the Java program being analyzed, it will not be recorded;

Store the result in the form of ClassStructure class, and save the class information of the c _i class;

Step S23: Process attributes, including:

Extract the attribute information of each class in the class collection;

Define an attribute information iterator, load class attribute information and traverse:

Get the attribute information data structure;

get attribute name;

get attribute type;

Get attribute permissions:

Return value 0: default; return value 1: public; return value 2: private; return value 4: protected;

Store the result in the form of FieldStructure class, and save the attribute information of the c _i class;

Step S24: a processing method, including:

Extract the method information of each class collection/interface collection;

Define method information iterator, load class method information and traverse, including:

Get method information data structure;

get method permission;

get return type;

get method name;

get parameter list;

The parameters of the method are stored separately;

Store the result in the form of the MethodStructure class, and save the method information of the c _i class;

Step S25: Process the inheritance relationship, including:

Define the inheritance relationship storage structure;

The format is: parent class<|--subclass;

Get the parent class of a class and store the inheritance relationship;

Step S26: Process the realization relationship, including:

Define the implementation relational storage structure;

Get the interface of a class;

Generate iterators and store implementation relationships;

Step S27: Process the association relationship, including:

Define the relationship storage structure;

Determine whether there is a relationship:

Determine whether it is 1 to 1;

Determine whether it is 1-to-many;

Step S28: Process dependencies, including:

Define the dependency storage structure;

get dependencies;

Step S29: Process the calling relationship tree, including the following steps:

first step:

Get the left half of U _ij .ValueBox;

Get the right half of U _ij .ValueBox;

Step 2:

If it is an assignment statement and there is a method call, then:

Get the called method and record the call information;

If it is a call statement, then:

Get the called method and record the call information;

third step:

Construct InvokeTree;

In step S3, calculating the similarity through the predefined class similarity evaluation factors specifically includes the following steps:

The similarity between class _i and class _j is calculated by using the class names of class _i and class _j , the number of attributes, the number of methods, the proportion of similar attributes, and the proportion of similar methods.

sc _ij =0.1*r _1ij +0.2*r _2ij +0.2*r _3ij +0.25*r _4ij +0.25*r _5ij ;

where fnum _i is the number of attributes in class _i , fnum _j is the number of attributes in class _j , mnum _i is the number of methods in class _i , mnum _j is the number of methods in class _j , and fnum _ij is the number of methods in class _i and class _j The number of the same attributes in class i and class j, mnum _ij is the number of the same methods in class _i and class _j ;

In step S4, calculating the similarity by the predefined method similarity evaluation factors specifically includes the following steps:

In terms of the similarity between the classes of methods m _i and m _j , the number of times the method is called, the number of times the method calls other methods, the method set m i.call that calls m _i and the method set m _j that calls _m _j The proportion of method pairs with a mapping relationship in .call, the method set called by m _i m _i .becall and the method set called by m _j m _j . The proportion of method pairs with a mapping relationship in .becall and the method signature are calculated by 6 evaluation factors Similarity of methods m _i and m _j :

sm _ij =0.15*p _1ij +0.2*p _2ij +0.2*p _3ij +0.15*p _4ij +0.15*p _5ij +0.15*p _6ij ;

p _1ij =sc _ab ;

p _6ij =0.8*sim _1ij +0.2*sim _2ij ;

Among them, becallm _ij is the number of method pairs that have a mapping relationship in mi.becall and mj.becall, becallnum _ij is the number of elements of _mi.becall or _mj.becall _, and _callm _ij is _mi.call and m The number of method pairs with mapping relationship in j.call, _{callnum ij} _is the number of elements of m _i.call or m _j.call .

2. the method for establishing different version program class sets mapping relationship according to claim 1, is characterized in that: step S5 specifically comprises:

Take the method pair with the highest similarity, establish a "one-to-one" mapping of methods, gradually adjust the similarity of the classes through the mapping relationship of the methods, and update the similarity between the classes in a step-by-step iterative manner. When the last method determines the mapping The relationship, the similarity of the classes is also finally determined, a threshold is determined, the mapping relationship of the classes is established, and the "one-to-one" or "one-to-many" or "many-to-one" mapping relationship of the classes is finally obtained.

3. the method for establishing different version program class sets mapping relationship according to claim 1, is characterized in that: described class similarity evaluation factor comprises: class name, attribute number, method number, similar attribute ratio and similar The proportion of methods; the method similarity evaluation factors include: the similarity between the classes to which the method belongs, the frequency of the method being called, the frequency of the method calling other methods, and the existence of a mapping in the method set that calls these two methods The proportion of method pairs of the relationship, the proportion of method pairs with a mapping relationship in the method set called by these two methods, and the method signature.

4. the method for setting up different version program class sets mapping relationship according to claim 2 is characterized in that: step S5 is specifically realized by following algorithm:

The method of entering the new version of the program;

The way to enter the old version of the program;

Enter the preliminary class similarity matrix simClass;

Input method similarity matrix simMethod;

Traverse the method similarity matrix until all methods in the new version of the program have established mapping relationships:

Find the method pair with the highest similarity in the method similarity matrix, and store the method pair and the corresponding similarity in the method mapping table;

Update the similarity of the two classes to which the method belongs according to the formula sc _ij =(sc _ij +1)/2, thereby updating the class similarity matrix;

update becallm _ij , increment it by one;

update callm _ij , increment it by one;

Update method similarity matrix;

Update the class similarity matrix;

Traverse the class similarity matrix, if the similarity of the two classes is greater than the threshold, store the two classes and their corresponding similarity in the class mapping table;

Output method mapping table and class mapping table.
