1// SPDX-License-Identifier: GPL-2.0-only
2/*
3 * Copyright 2020 Linaro Limited
4 *
5 * Author: Daniel Lezcano <daniel.lezcano@linaro.org>
6 *
7 * The powercap based Dynamic Thermal Power Management framework
8 * provides to the userspace a consistent API to set the power limit
9 * on some devices.
10 *
11 * DTPM defines the functions to create a tree of constraints. Each
12 * parent node is a virtual description of the aggregation of the
13 * children. It propagates the constraints set at its level to its
14 * children and collect the children power information. The leaves of
15 * the tree are the real devices which have the ability to get their
16 * current power consumption and set their power limit.
17 */
18#define pr_fmt(fmt) KBUILD_MODNAME ": " fmt
19
20#include <linux/dtpm.h>
21#include <linux/init.h>
22#include <linux/kernel.h>
23#include <linux/powercap.h>
24#include <linux/slab.h>
25#include <linux/mutex.h>
26#include <linux/of.h>
27
28#include "dtpm_subsys.h"
29
30#define DTPM_POWER_LIMIT_FLAG 0
31
32static const char *constraint_name[] = {
33 "Instantaneous",
34};
35
36static DEFINE_MUTEX(dtpm_lock);
37static struct powercap_control_type *pct;
38static struct dtpm *root;
39
40static int get_time_window_us(struct powercap_zone *pcz, int cid, u64 *window)
41{
42 return -ENOSYS;
43}
44
45static int set_time_window_us(struct powercap_zone *pcz, int cid, u64 window)
46{
47 return -ENOSYS;
48}
49
50static int get_max_power_range_uw(struct powercap_zone *pcz, u64 *max_power_uw)
51{
52 struct dtpm *dtpm = to_dtpm(zone: pcz);
53
54 *max_power_uw = dtpm->power_max - dtpm->power_min;
55
56 return 0;
57}
58
59static int __get_power_uw(struct dtpm *dtpm, u64 *power_uw)
60{
61 struct dtpm *child;
62 u64 power;
63 int ret = 0;
64
65 if (dtpm->ops) {
66 *power_uw = dtpm->ops->get_power_uw(dtpm);
67 return 0;
68 }
69
70 *power_uw = 0;
71
72 list_for_each_entry(child, &dtpm->children, sibling) {
73 ret = __get_power_uw(dtpm: child, power_uw: &power);
74 if (ret)
75 break;
76 *power_uw += power;
77 }
78
79 return ret;
80}
81
82static int get_power_uw(struct powercap_zone *pcz, u64 *power_uw)
83{
84 return __get_power_uw(dtpm: to_dtpm(zone: pcz), power_uw);
85}
86
87static void __dtpm_rebalance_weight(struct dtpm *dtpm)
88{
89 struct dtpm *child;
90
91 list_for_each_entry(child, &dtpm->children, sibling) {
92
93 pr_debug("Setting weight '%d' for '%s'\n",
94 child->weight, child->zone.name);
95
96 child->weight = DIV64_U64_ROUND_CLOSEST(
97 child->power_max * 1024, dtpm->power_max);
98
99 __dtpm_rebalance_weight(dtpm: child);
100 }
101}
102
103static void __dtpm_sub_power(struct dtpm *dtpm)
104{
105 struct dtpm *parent = dtpm->parent;
106
107 while (parent) {
108 parent->power_min -= dtpm->power_min;
109 parent->power_max -= dtpm->power_max;
110 parent->power_limit -= dtpm->power_limit;
111 parent = parent->parent;
112 }
113}
114
115static void __dtpm_add_power(struct dtpm *dtpm)
116{
117 struct dtpm *parent = dtpm->parent;
118
119 while (parent) {
120 parent->power_min += dtpm->power_min;
121 parent->power_max += dtpm->power_max;
122 parent->power_limit += dtpm->power_limit;
123 parent = parent->parent;
124 }
125}
126
127/**
128 * dtpm_update_power - Update the power on the dtpm
129 * @dtpm: a pointer to a dtpm structure to update
130 *
131 * Function to update the power values of the dtpm node specified in
132 * parameter. These new values will be propagated to the tree.
133 *
134 * Return: zero on success, -EINVAL if the values are inconsistent
135 */
136int dtpm_update_power(struct dtpm *dtpm)
137{
138 int ret;
139
140 __dtpm_sub_power(dtpm);
141
142 ret = dtpm->ops->update_power_uw(dtpm);
143 if (ret)
144 pr_err("Failed to update power for '%s': %d\n",
145 dtpm->zone.name, ret);
146
147 if (!test_bit(DTPM_POWER_LIMIT_FLAG, &dtpm->flags))
148 dtpm->power_limit = dtpm->power_max;
149
150 __dtpm_add_power(dtpm);
151
152 if (root)
153 __dtpm_rebalance_weight(dtpm: root);
154
155 return ret;
156}
157
158/**
159 * dtpm_release_zone - Cleanup when the node is released
160 * @pcz: a pointer to a powercap_zone structure
161 *
162 * Do some housecleaning and update the weight on the tree. The
163 * release will be denied if the node has children. This function must
164 * be called by the specific release callback of the different
165 * backends.
166 *
167 * Return: 0 on success, -EBUSY if there are children
168 */
169int dtpm_release_zone(struct powercap_zone *pcz)
170{
171 struct dtpm *dtpm = to_dtpm(zone: pcz);
172 struct dtpm *parent = dtpm->parent;
173
174 if (!list_empty(head: &dtpm->children))
175 return -EBUSY;
176
177 if (parent)
178 list_del(entry: &dtpm->sibling);
179
180 __dtpm_sub_power(dtpm);
181
182 if (dtpm->ops)
183 dtpm->ops->release(dtpm);
184 else
185 kfree(objp: dtpm);
186
187 return 0;
188}
189
190static int get_power_limit_uw(struct powercap_zone *pcz,
191 int cid, u64 *power_limit)
192{
193 *power_limit = to_dtpm(zone: pcz)->power_limit;
194
195 return 0;
196}
197
198/*
199 * Set the power limit on the nodes, the power limit is distributed
200 * given the weight of the children.
201 *
202 * The dtpm node lock must be held when calling this function.
203 */
204static int __set_power_limit_uw(struct dtpm *dtpm, int cid, u64 power_limit)
205{
206 struct dtpm *child;
207 int ret = 0;
208 u64 power;
209
210 /*
211 * A max power limitation means we remove the power limit,
212 * otherwise we set a constraint and flag the dtpm node.
213 */
214 if (power_limit == dtpm->power_max) {
215 clear_bit(DTPM_POWER_LIMIT_FLAG, addr: &dtpm->flags);
216 } else {
217 set_bit(DTPM_POWER_LIMIT_FLAG, addr: &dtpm->flags);
218 }
219
220 pr_debug("Setting power limit for '%s': %llu uW\n",
221 dtpm->zone.name, power_limit);
222
223 /*
224 * Only leaves of the dtpm tree has ops to get/set the power
225 */
226 if (dtpm->ops) {
227 dtpm->power_limit = dtpm->ops->set_power_uw(dtpm, power_limit);
228 } else {
229 dtpm->power_limit = 0;
230
231 list_for_each_entry(child, &dtpm->children, sibling) {
232
233 /*
234 * Integer division rounding will inevitably
235 * lead to a different min or max value when
236 * set several times. In order to restore the
237 * initial value, we force the child's min or
238 * max power every time if the constraint is
239 * at the boundaries.
240 */
241 if (power_limit == dtpm->power_max) {
242 power = child->power_max;
243 } else if (power_limit == dtpm->power_min) {
244 power = child->power_min;
245 } else {
246 power = DIV_ROUND_CLOSEST_ULL(
247 power_limit * child->weight, 1024);
248 }
249
250 pr_debug("Setting power limit for '%s': %llu uW\n",
251 child->zone.name, power);
252
253 ret = __set_power_limit_uw(dtpm: child, cid, power_limit: power);
254 if (!ret)
255 ret = get_power_limit_uw(pcz: &child->zone, cid, power_limit: &power);
256
257 if (ret)
258 break;
259
260 dtpm->power_limit += power;
261 }
262 }
263
264 return ret;
265}
266
267static int set_power_limit_uw(struct powercap_zone *pcz,
268 int cid, u64 power_limit)
269{
270 struct dtpm *dtpm = to_dtpm(zone: pcz);
271 int ret;
272
273 /*
274 * Don't allow values outside of the power range previously
275 * set when initializing the power numbers.
276 */
277 power_limit = clamp_val(power_limit, dtpm->power_min, dtpm->power_max);
278
279 ret = __set_power_limit_uw(dtpm, cid, power_limit);
280
281 pr_debug("%s: power limit: %llu uW, power max: %llu uW\n",
282 dtpm->zone.name, dtpm->power_limit, dtpm->power_max);
283
284 return ret;
285}
286
287static const char *get_constraint_name(struct powercap_zone *pcz, int cid)
288{
289 return constraint_name[cid];
290}
291
292static int get_max_power_uw(struct powercap_zone *pcz, int id, u64 *max_power)
293{
294 *max_power = to_dtpm(zone: pcz)->power_max;
295
296 return 0;
297}
298
299static struct powercap_zone_constraint_ops constraint_ops = {
300 .set_power_limit_uw = set_power_limit_uw,
301 .get_power_limit_uw = get_power_limit_uw,
302 .set_time_window_us = set_time_window_us,
303 .get_time_window_us = get_time_window_us,
304 .get_max_power_uw = get_max_power_uw,
305 .get_name = get_constraint_name,
306};
307
308static struct powercap_zone_ops zone_ops = {
309 .get_max_power_range_uw = get_max_power_range_uw,
310 .get_power_uw = get_power_uw,
311 .release = dtpm_release_zone,
312};
313
314/**
315 * dtpm_init - Allocate and initialize a dtpm struct
316 * @dtpm: The dtpm struct pointer to be initialized
317 * @ops: The dtpm device specific ops, NULL for a virtual node
318 */
319void dtpm_init(struct dtpm *dtpm, struct dtpm_ops *ops)
320{
321 if (dtpm) {
322 INIT_LIST_HEAD(list: &dtpm->children);
323 INIT_LIST_HEAD(list: &dtpm->sibling);
324 dtpm->weight = 1024;
325 dtpm->ops = ops;
326 }
327}
328
329/**
330 * dtpm_unregister - Unregister a dtpm node from the hierarchy tree
331 * @dtpm: a pointer to a dtpm structure corresponding to the node to be removed
332 *
333 * Call the underlying powercap unregister function. That will call
334 * the release callback of the powercap zone.
335 */
336void dtpm_unregister(struct dtpm *dtpm)
337{
338 powercap_unregister_zone(control_type: pct, power_zone: &dtpm->zone);
339
340 pr_debug("Unregistered dtpm node '%s'\n", dtpm->zone.name);
341}
342
343/**
344 * dtpm_register - Register a dtpm node in the hierarchy tree
345 * @name: a string specifying the name of the node
346 * @dtpm: a pointer to a dtpm structure corresponding to the new node
347 * @parent: a pointer to a dtpm structure corresponding to the parent node
348 *
349 * Create a dtpm node in the tree. If no parent is specified, the node
350 * is the root node of the hierarchy. If the root node already exists,
351 * then the registration will fail. The powercap controller must be
352 * initialized before calling this function.
353 *
354 * The dtpm structure must be initialized with the power numbers
355 * before calling this function.
356 *
357 * Return: zero on success, a negative value in case of error:
358 * -EAGAIN: the function is called before the framework is initialized.
359 * -EBUSY: the root node is already inserted
360 * -EINVAL: * there is no root node yet and @parent is specified
361 * * no all ops are defined
362 * * parent have ops which are reserved for leaves
363 * Other negative values are reported back from the powercap framework
364 */
365int dtpm_register(const char *name, struct dtpm *dtpm, struct dtpm *parent)
366{
367 struct powercap_zone *pcz;
368
369 if (!pct)
370 return -EAGAIN;
371
372 if (root && !parent)
373 return -EBUSY;
374
375 if (!root && parent)
376 return -EINVAL;
377
378 if (parent && parent->ops)
379 return -EINVAL;
380
381 if (!dtpm)
382 return -EINVAL;
383
384 if (dtpm->ops && !(dtpm->ops->set_power_uw &&
385 dtpm->ops->get_power_uw &&
386 dtpm->ops->update_power_uw &&
387 dtpm->ops->release))
388 return -EINVAL;
389
390 pcz = powercap_register_zone(power_zone: &dtpm->zone, control_type: pct, name,
391 parent: parent ? &parent->zone : NULL,
392 ops: &zone_ops, MAX_DTPM_CONSTRAINTS,
393 const_ops: &constraint_ops);
394 if (IS_ERR(ptr: pcz))
395 return PTR_ERR(ptr: pcz);
396
397 if (parent) {
398 list_add_tail(new: &dtpm->sibling, head: &parent->children);
399 dtpm->parent = parent;
400 } else {
401 root = dtpm;
402 }
403
404 if (dtpm->ops && !dtpm->ops->update_power_uw(dtpm)) {
405 __dtpm_add_power(dtpm);
406 dtpm->power_limit = dtpm->power_max;
407 }
408
409 pr_debug("Registered dtpm node '%s' / %llu-%llu uW, \n",
410 dtpm->zone.name, dtpm->power_min, dtpm->power_max);
411
412 return 0;
413}
414
415static struct dtpm *dtpm_setup_virtual(const struct dtpm_node *hierarchy,
416 struct dtpm *parent)
417{
418 struct dtpm *dtpm;
419 int ret;
420
421 dtpm = kzalloc(sizeof(*dtpm), GFP_KERNEL);
422 if (!dtpm)
423 return ERR_PTR(error: -ENOMEM);
424 dtpm_init(dtpm, NULL);
425
426 ret = dtpm_register(name: hierarchy->name, dtpm, parent);
427 if (ret) {
428 pr_err("Failed to register dtpm node '%s': %d\n",
429 hierarchy->name, ret);
430 kfree(objp: dtpm);
431 return ERR_PTR(error: ret);
432 }
433
434 return dtpm;
435}
436
437static struct dtpm *dtpm_setup_dt(const struct dtpm_node *hierarchy,
438 struct dtpm *parent)
439{
440 struct device_node *np;
441 int i, ret;
442
443 np = of_find_node_by_path(path: hierarchy->name);
444 if (!np) {
445 pr_err("Failed to find '%s'\n", hierarchy->name);
446 return ERR_PTR(error: -ENXIO);
447 }
448
449 for (i = 0; i < ARRAY_SIZE(dtpm_subsys); i++) {
450
451 if (!dtpm_subsys[i]->setup)
452 continue;
453
454 ret = dtpm_subsys[i]->setup(parent, np);
455 if (ret) {
456 pr_err("Failed to setup '%s': %d\n", dtpm_subsys[i]->name, ret);
457 of_node_put(node: np);
458 return ERR_PTR(error: ret);
459 }
460 }
461
462 of_node_put(node: np);
463
464 /*
465 * By returning a NULL pointer, we let know the caller there
466 * is no child for us as we are a leaf of the tree
467 */
468 return NULL;
469}
470
471typedef struct dtpm * (*dtpm_node_callback_t)(const struct dtpm_node *, struct dtpm *);
472
473static dtpm_node_callback_t dtpm_node_callback[] = {
474 [DTPM_NODE_VIRTUAL] = dtpm_setup_virtual,
475 [DTPM_NODE_DT] = dtpm_setup_dt,
476};
477
478static int dtpm_for_each_child(const struct dtpm_node *hierarchy,
479 const struct dtpm_node *it, struct dtpm *parent)
480{
481 struct dtpm *dtpm;
482 int i, ret;
483
484 for (i = 0; hierarchy[i].name; i++) {
485
486 if (hierarchy[i].parent != it)
487 continue;
488
489 dtpm = dtpm_node_callback[hierarchy[i].type](&hierarchy[i], parent);
490
491 /*
492 * A NULL pointer means there is no children, hence we
493 * continue without going deeper in the recursivity.
494 */
495 if (!dtpm)
496 continue;
497
498 /*
499 * There are multiple reasons why the callback could
500 * fail. The generic glue is abstracting the backend
501 * and therefore it is not possible to report back or
502 * take a decision based on the error. In any case,
503 * if this call fails, it is not critical in the
504 * hierarchy creation, we can assume the underlying
505 * service is not found, so we continue without this
506 * branch in the tree but with a warning to log the
507 * information the node was not created.
508 */
509 if (IS_ERR(ptr: dtpm)) {
510 pr_warn("Failed to create '%s' in the hierarchy\n",
511 hierarchy[i].name);
512 continue;
513 }
514
515 ret = dtpm_for_each_child(hierarchy, it: &hierarchy[i], parent: dtpm);
516 if (ret)
517 return ret;
518 }
519
520 return 0;
521}
522
523/**
524 * dtpm_create_hierarchy - Create the dtpm hierarchy
525 * @dtpm_match_table: Pointer to the array of device ID structures
526 *
527 * The function is called by the platform specific code with the
528 * description of the different node in the hierarchy. It creates the
529 * tree in the sysfs filesystem under the powercap dtpm entry.
530 *
531 * The expected tree has the format:
532 *
533 * struct dtpm_node hierarchy[] = {
534 * [0] { .name = "topmost", type = DTPM_NODE_VIRTUAL },
535 * [1] { .name = "package", .type = DTPM_NODE_VIRTUAL, .parent = &hierarchy[0] },
536 * [2] { .name = "/cpus/cpu0", .type = DTPM_NODE_DT, .parent = &hierarchy[1] },
537 * [3] { .name = "/cpus/cpu1", .type = DTPM_NODE_DT, .parent = &hierarchy[1] },
538 * [4] { .name = "/cpus/cpu2", .type = DTPM_NODE_DT, .parent = &hierarchy[1] },
539 * [5] { .name = "/cpus/cpu3", .type = DTPM_NODE_DT, .parent = &hierarchy[1] },
540 * [6] { }
541 * };
542 *
543 * The last element is always an empty one and marks the end of the
544 * array.
545 *
546 * Return: zero on success, a negative value in case of error. Errors
547 * are reported back from the underlying functions.
548 */
549int dtpm_create_hierarchy(struct of_device_id *dtpm_match_table)
550{
551 const struct dtpm_node *hierarchy;
552 int i, ret;
553
554 mutex_lock(&dtpm_lock);
555
556 if (pct) {
557 ret = -EBUSY;
558 goto out_unlock;
559 }
560
561 pct = powercap_register_control_type(NULL, name: "dtpm", NULL);
562 if (IS_ERR(ptr: pct)) {
563 pr_err("Failed to register control type\n");
564 ret = PTR_ERR(ptr: pct);
565 goto out_pct;
566 }
567
568 hierarchy = of_machine_get_match_data(matches: dtpm_match_table);
569 if (!hierarchy) {
570 ret = -EFAULT;
571 goto out_err;
572 }
573
574 ret = dtpm_for_each_child(hierarchy, NULL, NULL);
575 if (ret)
576 goto out_err;
577
578 for (i = 0; i < ARRAY_SIZE(dtpm_subsys); i++) {
579
580 if (!dtpm_subsys[i]->init)
581 continue;
582
583 ret = dtpm_subsys[i]->init();
584 if (ret)
585 pr_info("Failed to initialize '%s': %d",
586 dtpm_subsys[i]->name, ret);
587 }
588
589 mutex_unlock(lock: &dtpm_lock);
590
591 return 0;
592
593out_err:
594 powercap_unregister_control_type(instance: pct);
595out_pct:
596 pct = NULL;
597out_unlock:
598 mutex_unlock(lock: &dtpm_lock);
599
600 return ret;
601}
602EXPORT_SYMBOL_GPL(dtpm_create_hierarchy);
603
604static void __dtpm_destroy_hierarchy(struct dtpm *dtpm)
605{
606 struct dtpm *child, *aux;
607
608 list_for_each_entry_safe(child, aux, &dtpm->children, sibling)
609 __dtpm_destroy_hierarchy(dtpm: child);
610
611 /*
612 * At this point, we know all children were removed from the
613 * recursive call before
614 */
615 dtpm_unregister(dtpm);
616}
617
618void dtpm_destroy_hierarchy(void)
619{
620 int i;
621
622 mutex_lock(&dtpm_lock);
623
624 if (!pct)
625 goto out_unlock;
626
627 __dtpm_destroy_hierarchy(dtpm: root);
628
629
630 for (i = 0; i < ARRAY_SIZE(dtpm_subsys); i++) {
631
632 if (!dtpm_subsys[i]->exit)
633 continue;
634
635 dtpm_subsys[i]->exit();
636 }
637
638 powercap_unregister_control_type(instance: pct);
639
640 pct = NULL;
641
642 root = NULL;
643
644out_unlock:
645 mutex_unlock(lock: &dtpm_lock);
646}
647EXPORT_SYMBOL_GPL(dtpm_destroy_hierarchy);
648

source code of linux/drivers/powercap/dtpm.c
